Elevated Planter Box
Installation Guide
Thank You!
You're only a few steps away from your perfect vegetable
garden or elevated planter. We hope you enjoy!
Before You Start
Please read the instructions carefully to familiarize
yourself with every detail and step involved. Keep this
manual for future reference. Find a suitable space to
assemble your new Elevated Planter Box.
You need at least 18" x 20" (46 x 51cm) for the finished
product. A flat and firm area (like a garage floor or flat
yard space) is perfect! The only tool you may need is a
rubber mallet.
Important Notes
Small parts are included; we advise you to keep
them away from children and pets.
We also suggest having another person help you
assemble. Maximum Load Capacity: approximately
2.8 cu. ft. of soil
Subscribe at www.everbloom-garden.com
for extra savings and upgrading information!
Everbloom-Garden.com
Questions or Comments?
Email us at service@everbloom-garden.com
Model# E281719 / E281719G
Dimensions 17" L x 19" W x 28" H
1
Advertisement
Related Manuals for Everbloom E281719
Summary of Contents for Everbloom E281719
- Page 1 Elevated Planter Box Installation Guide Thank You! Model# E281719 / E281719G Dimensions 17" L x 19" W x 28" H You’re only a few steps away from your perfect vegetable garden or elevated planter. We hope you enjoy! Before You Start Please read the instructions carefully to familiarize yourself with every detail and step involved.
-
Page 2: Parts List
Parts List Elevated Planter Box - 17" L x 19" W x 28" H Left Corner Right Corner Short Short Bottom Post Post Board A Board B Board 420mm 420mm 460mm Bottom Bottom Post Cap Garden Bed Liner + 2pc replacement... - Page 3 Assembly Elevated Planter Box - 17" L x 19" W x 28" H There are 2 different assembly methods providing 2 different planting depths: 10” (as shown in Image 1) and 7.5” (as shown in Image 2). * For deeper planting depth of 10”, please follow steps from page 4. * For easier but shallower planting depth of 7.5”, please go to page 10.
- Page 4 Assembly Elevated Planter Box - 17" L x 19" W x 28" H Start by making sure each corner post is oriented correctly, as shown in Image 3. Slide one short board B into the corner brackets from above. Note: The short boards need to be placed in the inward “U” shape of the brackets, as shown in Image 4. IMAGE 3 IMAGE 4 Short...
- Page 5 Assembly Elevated Planter Box - 17" L x 19" W x 28" H Slide another short board B into the other two corner brackets from above, as shown in Image 5. IMAGE 5 Right Corner Post Left Corner Post Left Corner Post Right Corner Post...
- Page 6 Assembly Elevated Planter Box - 17" L x 19" W x 28" H With the help of another person holding the 2 assembled parts, slide another two short boards B into the brackets from above. Make sure that one short board B goes straight to the bottom, while the other one stays in the middle of the way (don’t push to the bottom), with the top edge between the 2nd and 3rd holes of the post.
- Page 7 Assembly Elevated Planter Box - 17" L x 19" W x 28" H Put the bottom boards on lower slots of short boards B. Make sure the 2 ends of these bottom boards go into the lower slots and rest in them with enough contact as shown in Image 7. Adjust the height of the higher short board B slightly to hold these bottom boards if necessary.
- Page 8 Assembly Elevated Planter Box - 17" L x 19" W x 28" H Push down the higher short board B to the bottom, as shown in Image 8. IMAGE 8 Short Board B Short Board B...
- Page 9 Assembly Elevated Planter Box - 17" L x 19" W x 28" H Slide the remaining boards into place, as shown in Image 9. Now you get an elevated planter box with 10” planting depth. Then, go to page 15, and follow the steps afterwards. IMAGE 9 Short Board A...
- Page 10 Assembly Elevated Planter Box - 17" L x 19" W x 28" H Start by making sure each corner post is oriented correctly, as shown in Image 3a. Slide one short board B into the corner brackets from above. Note: The short boards need to be placed in the inward “U” shape of the brackets, as shown in Image 4a. IMAGE 3a IMAGE 4a Short...
- Page 11 Assembly Elevated Planter Box - 17" L x 19" W x 28" H Slide another short board B into the other two corner brackets from above, as shown in Image 5a. IMAGE 5a Right Corner Post Left Corner Post Left Corner Post Right Corner Post...
- Page 12 Assembly Elevated Planter Box - 17" L x 19" W x 28" H With the help of another person holding the 2 assembled parts, slide the other two short boards B into the brackets from above, as shown in Image 6a. IMAGE 6a Short Board B...
- Page 13 Assembly Elevated Planter Box - 17" L x 19" W x 28" H Put the bottom boards on the long support boards, as shown in Image 7a. IMAGE 7a Bottom Board Short Short Board B Board B...
- Page 14 Assembly Elevated Planter Box - 17" L x 19" W x 28" H Slide the remaining boards into place, as shown in Image 8a. Now you get an elevated planter box with 7.5” planting depth. IMAGE 8a Short Board A Short Board B...
- Page 15 Assembly Elevated Planter Box - 17" L x 19" W x 28" H If necessary, use your rubber mallet to ensure the boards are tightly in place. Cover the brackets with the 4 end caps, as shown in Image 10. IMAGE 10 Rubber Mallet...
- Page 16 Assembly Elevated Planter Box - 17" L x 19" W x 28" H For additional stability, we highly suggest using the included 8 self-tapping screws with washers (Image 11). Fasten 2 screws into each side of the inward facing corner posts using a #2 Phillips screwdriver (not includ- ed), as shown in Image 12.
- Page 17 Assembly Elevated Planter Box - 17" L x 19" W x 28" H Unfold the liner and cover the bottom of the garden bed, as shown in Image 14 and Image 15. IMAGE 14 Garden Bed Liner IMAGE 15...
- Page 18 Note Elevated Planter Box - 17" L x 19" W x 28" H Sometimes there might be a misalignment of the Corner Posts as shown in Image 16 and Image 17, which may result in difficulty of sliding boards into the brackets. Please adjust them to the right position so that they are parallel to each other, and perpendicular to the ground.
- Page 19 Bloom On. Everbloom-Garden.com US Patent Pending Subscribe at www.everbloom-garden.com for extra savings and upgrading information! Distributed by: Dynaforge Trading LLC St. Paul, MN55101 Email: service@everbloom-garden.com...
