H-Type Raised Garden Bed
Installation Guide
Thank You!
You're only a few steps away from your perfect vegetable
garden or elevated planter. We hope you enjoy!
Before You Start
Please read the instructions carefully to familiarize
yourself with every detail and step involved. Keep this
manual for future reference. Find a suitable space to
assemble your new H-Type Raised Garden Bed.
You need at least 109" x 109" (277 x 277cm) for the
finished product. A flat and firm area (like a garage floor
or flat yard space) is perfect! The only tool you may
need is a rubber mallet.
Important Notes
Small parts are included; we advise you to keep
them away from children and pets.
We also suggest having another person help you
assemble. Maximum Load capacity: approximately
55 cu. ft. of soil
Subscribe at www.everbloom-garden.com
for extra savings and upgrading information!
Everbloom-Garden.com
Questions or Comments?
Email us at service@everbloom-garden.com
Dimensions 108" L x 108" W x 7" & 14" H
This product is bundled by:
Model#
R073638 -2pc
Essential Raised
Garden Bed
Bundle# K2206
Model# R0714E36 -2pc
Terraced Double
Bed Extension
1
Advertisement
Related Manuals for Everbloom R073638
Summary of Contents for Everbloom R073638
- Page 1 R073638 -2pc Model# R0714E36 -2pc assemble. Maximum Load capacity: approximately Essential Raised Terraced Double 55 cu. ft. of soil Garden Bed Bed Extension Subscribe at www.everbloom-garden.com for extra savings and upgrading information! Everbloom-Garden.com Questions or Comments? Email us at service@everbloom-garden.com...
-
Page 2: Parts List
Right Corner Long Board Left Joiner Right Joiner Post Post X 24 Corner Corner (180mm) X 4 (180mm) X 4 From R073638 / From R073638 From R073638 R0714E36 From R0714E36 From R0714E36 Bottom Bottom Bottom Bottom Post Cap X 24... - Page 3 Assembly H-Type Raised Garden Bed - 108" L x 108" W x 7" & 14" H Start by making sure each corner post is oriented correctly. Reference Image 1. IMAGE 1 Right Corner Post (180mm) Left Corner Post (180mm) Right Corner Right Joiner Post Corner...
- Page 4 Assembly H-Type Raised Garden Bed - 108" L x 108" W x 7" & 14" H Fix the left joiner corner and left corner post (180mm) on one long board from above, as shown in Image 2. Note: The boards need to be placed in the inward “U” shape of the brackets. (Image 2). IMAGE 2 Left Joiner Corner...
- Page 5 Assembly H-Type Raised Garden Bed - 108" L x 108" W x 7" & 14" H Fix other joiner corners and corner posts (180mm) on long boards from above, as shown in Image 3. IMAGE 3 Right Corner Post (180mm) Right Joiner Corner Long...
- Page 6 Assembly H-Type Raised Garden Bed - 108" L x 108" W x 7" & 14" H Slide eight long boards to form the first layer of the garden bed, as shown in Image 4. IMAGE 4 Long Board Long Long Board Board Long...
- Page 7 Assembly H-Type Raised Garden Bed - 108" L x 108" W x 7" & 14" H Slide the remaining eight long boards to form the second layer of the garden bed, as shown in Image 5. IMAGE 5 Long Board Long Board Long...
- Page 8 Assembly H-Type Raised Garden Bed - 108" L x 108" W x 7" & 14" H If necessary, use your rubber mallet to ensure the boards are tightly in place. Cover the brackets with the 12 end caps, as shown in Image 6. Now you get a H-Type raised garden bed. IMAGE 6 Rubber Mallet...
- Page 9 Assembly H-Type Raised Garden Bed - 108" L x 108" W x 7" & 14" H For the central 4 ends of post brackets, you can use remaining post caps to cover them and trim by scissor, as shown in Image 7. IMAGE 7 Post Cap Post Cap...
- Page 10 Notes H-Type Raised Garden Bed - 108" L x 108" W x 7" & 14" H Sometimes there might be a misalignment of the Corner Posts as shown in Image 8 and Image 9, which may result in difficulty of sliding boards into the brackets. Please adjust them to the right position so that they are parallel to each other, and perpendicular to the ground.
- Page 11 Bloom On. Everbloom-Garden.com US Patent Pending Subscribe at www.everbloom-garden.com for extra savings and upgrading information! Distributed by: Dynaforge Trading LLC St. Paul, MN55101 Email: service@everbloom-garden.com...
