Rolling Trough garden Planter
Installation Guide
Thank You!
You're only a few steps away from your perfect vegetable
garden or elevated planter. We hope you enjoy!
Before You Start
Please read the instructions carefully to familiarize
yourself with every detail and step involved. Keep this
manual for future reference. Find a suitable space to
assemble your new Elevated Garden Planter.
You need at least 37" x 13" (94 x 33 cm) for the finished
product. A flat and firm area (like a garage floor or flat
yard space) is perfect! The only tool you may need is a
rubber mallet.
Important Notes
Small parts are included; we advise you to keep
them away from children and pets.
We also suggest having another person help you
assemble. Maximum Load capacity: approximately
1.4 cu. ft. of soil
Subscribe at www.everbloom-garden.com
for extra savings and upgrading information!
Everbloom-Garden.com
Questions or Comments?
Email us at service@everbloom-garden.com
Copyright © 2023 Dynaforge Trading LLC.
Model# E103612W
Dimensions 36" L x 12" W x 12.5" H
1
Advertisement
Related Manuals for Everbloom E103612W
Summary of Contents for Everbloom E103612W
- Page 1 We also suggest having another person help you assemble. Maximum Load capacity: approximately 1.4 cu. ft. of soil Subscribe at www.everbloom-garden.com for extra savings and upgrading information! Everbloom-Garden.com Questions or Comments? Email us at service@everbloom-garden.com Copyright © 2023 Dynaforge Trading LLC.
-
Page 2: Parts List
Parts List Rolling Trough Garden Planter - 36" L x 12" W x 12.5" H Left Corner Right Corner Long Support Short Post Cap Post Post Board Board + 2pc replacement 240mm Bottom Bottom Bottom Tray with End Caps 900mm Black Liner Tape... - Page 3 Assembly Rolling Trough Garden Planter - 36" L x 12" W x 12.5" H Start by making sure each corner post is oriented correctly, as shown in Image 1. Slide one short board into the corner brackets from above. Note: The short boards need to be placed in the inward “U” shape of the brackets, as shown in Image 1. IMAGE 2 IMAGE 1 Short...
- Page 4 Assembly Rolling Trough Garden Planter - 36" L x 12" W x 12.5" H Slide another short board into the other two corner brackets from above, as shown in Image 2. IMAGE 2 Right Corner Post Left Corner Post Left Corner Short Post...
- Page 5 Assembly Rolling Trough Garden Planter - 36" L x 12" W x 12.5" H With the help of another person holding the 2 assembled parts, slide the 2 long supporting boards into the brackets from above. Make sure that one support board goes straight to the bottom, while the other one stays in the middle of the way (don’t push to the bottom), with the bottom edge between the 2nd and 3rd holes of the post, as shown in Image 3.
- Page 6 Assembly Rolling Trough Garden Planter - 36" L x 12" W x 12.5" H Put the bottom trays on lower slots of long support boards. Make sure the 2 ends of these bottom trays go into the lower slots and rest in them with enough contact as shown in Image 4. Adjust the height of the higher long support board slightly to hold these bottom trays if necessary.
- Page 7 Assembly Rolling Trough Garden Planter - 36" L x 12" W x 12.5" H Push down the higher long support board to the bottom, as shown in Image 5. IMAGE 5 IMAGE 9 Long Support Board...
- Page 8 Assembly Rolling Trough Garden Planter - 36" L x 12" W x 12.5" H Seal the small gaps between reservoirs and the gaps between reservoir and short boards with black tape, as shown in Image 6. IMAGE 6 Black Tape...
- Page 9 Assembly Rolling Trough Garden Planter - 36" L x 12" W x 12.5" H Bottom trays come with 12 drainage holes each with end caps, enabling adjustable drainage settings. Take off some end caps in advance according to different climates and watering needs as you wish, as shown in Image 7.
- Page 10 Assembly Rolling Trough Garden Planter - 36" L x 12" W x 12.5" H Cover the holes with liners, as shown in Image 8. IMAGE 8 Liner x2...
- Page 11 Assembly Rolling Trough Garden Planter - 36" L x 12" W x 12.5" H If necessary, use your rubber mallet to ensure the boards are tightly in place. Cover the brackets with the 4 post caps, as shown in Image 9. IMAGE 9 Rubber Mallet...
- Page 12 Assembly Rolling Trough Garden Planter - 36" L x 12" W x 12.5" H Then you get an Everbloom Rolling Trough Garden Planter, as shown in Image 10. IMAGE 10 Note: Store the additional caps for future use.
- Page 13 Note Rolling Trough Garden Planter - 36" L x 12" W x 12.5" H Sometimes there might be a misalignment of the Corner Posts as shown in Image 11 and Image 12, which may result in difficulty of sliding boards into the brackets. Please adjust them to the right position so that they are parallel to each other, and perpendicular to the ground.
- Page 14 Bloom On. Everbloom-Garden.com US Patented Subscribe at www.everbloom-garden.com for extra savings and upgrading information! Distributed by: Dynaforge Trading LLC St. Paul, MN55101 Email: service@everbloom-garden.com...
