Elevated Garden Bed, wheeled
45" L x 18" W x 33" H
Installation Guide
BEFORE YOU START
Please Read the instructions carefully to familiarize yourself with every detail
and step involved. Keep this manual for future reference. Find a suitable
space to assemble the Everbloom Garden Bed.
You need at least 46" x 19" (117 x 49cm) for the finished product. A flat and
firm area (like a garage floor or flat yard space) is perfect! The only tool you
may need is a rubber mallet.
IMPORTANT NOTES
Small parts are included; we advise you to keep them away from children
and pets.
We also suggest having another person help you assemble.
Load capacity: approximately 4 cu. ft. of soil
E334518W
Advertisement
Related Manuals for Everbloom E334518W
Summary of Contents for Everbloom E334518W
- Page 1 Please Read the instructions carefully to familiarize yourself with every detail and step involved. Keep this manual for future reference. Find a suitable space to assemble the Everbloom Garden Bed. You need at least 46” x 19” (117 x 49cm) for the finished product. A flat and firm area (like a garage floor or flat yard space) is perfect! The only tool you may need is a rubber mallet.
-
Page 2: Parts List
PARTS LIST Elevated Garden Bed, wheeled 45” L x 18” W x 33" H Left Corner Right Corner Long Long Support Short Short Bottom Post Post Board Board Board A Board B Board 400mm 400mm 440mm Bottom Bottom 1140mm 1140mm Post Cap Caster Wheel Bolt... - Page 3 ASSEMBLY Elevated Garden Bed, wheeled 45” L x 18” W x 33" H Start by making sure each corner post is oriented correctly. Refer to image 1 and ensure that the 8 holes are on the bottom half of the standing corner posts. Slide one short board B into the corner brackets from above. Note: The short boards need to be placed in the inward “U”...
- Page 4 ASSEMBLY Elevated Garden Bed, wheeled 45” L x 18” W x 33" H Slide the long support boards into the corner posts, as shown in Image 3. Right Corner Post Long Support Board Left Corner Post Long Support Board Short Board B Image 3...
- Page 5 ASSEMBLY Elevated Garden Bed, wheeled 45” L x 18” W x 33" H Carefully flip over the garden bed so that it lays flat with the long support boards pointing towards the sky. Slide the bottom boards through the slots of the long support boards. All 4 boards can be slided in now. (image 4) Bottom Board Long Support...
- Page 6 ASSEMBLY Elevated Garden Bed, wheeled 45” L x 18” W x 33" H Slide the remaining corner posts into place as shown in Image 5. Ensure that the direction of the each post is symmetric for the remaining short board. Left Corner Post Right Corner...
- Page 7 ASSEMBLY Elevated Garden Bed, wheeled 45” L x 18” W x 33" H Slide one short board B into the corner brackets, as shown in Image 6. Left Corner Post Right Corner Post Bottom Board Short Board B Long Support Board Long Support Board...
- Page 8 ASSEMBLY Elevated Garden Bed, wheeled 45” L x 18” W x 33" H Flip over the bed so it stands upright. Slide the remaining boards into place, as shown in image 7. Short Board A Short Board A Long Board Long Board Image 7...
- Page 9 ASSEMBLY Elevated Garden Bed, wheeled 45” L x 18” W x 33" H Use the rubber mallet to ensure the boards are tightly in place. Cover the brackets with the 8 end caps, as shown in Image 8. Post Cap Rubber Mallet Post Cap...
- Page 10 ASSEMBLY Elevated Garden Bed, wheeled 45” L x 18” W x 33" H Carefully flip over the garden bed again so that it lays flat with the long support boards pointing towards the sky. Insert caster wheels into corner brackets, as shown in Image 9 and Image 10. Image 9 Image 10...
- Page 11 ASSEMBLY Elevated Garden Bed, wheeled 45” L x 18” W x 33" H Fix the wheels with bollts and nuts, as shown in Image 11. Image 11...
- Page 12 ASSEMBLY Elevated Garden Bed, wheeled 45” L x 18” W x 33" H Fasten bolts and nuts with nut driver and hex key which are included in pack , as shown in Image 12. Image 12...
- Page 13 ASSEMBLY Elevated Garden Bed, wheeled 45” L x 18” W x 33" H Flip over the bed again so it stands upright, as shown in Image 13. Image 13...
- Page 14 ASSEMBLY Elevated Garden Bed, wheeled 45” L x 18” W x 33" H Unfold the liner and cover the bottom of the garden bed, as shown in Image 14 and Image 15. Garden Bed Liner Image 14 Image 15...
- Page 15 Notes Elevated Garden Bed, wheeled 45” L x 18” W x 33" H Sometimes there might be mis-alignment of corner brackes as showed in Image 15 and Image 16, which may result in difficulty of sliding boards into the bracks. Please adjust them to the right position. ASSEMBLING PROBLEM 1 Image 15 ASSEMBLING PROBLEM 2...
- Page 16 Questions or Comments? Email us at service@everbloom-garden.com Welcome to our website: www.everbloom-garden.com Distributed by: Dynaforge Trading LLC St. Paul, MN55101 Email: service@everbloom-garden.com...
