Planter Box Cornerstone
Installation Guide
Thank You!
You're only a few steps away from your perfect vegetable
garden or elevated planter. We hope you enjoy!
Before You Start
Please read the instructions carefully to familiarize
yourself with every detail and step involved. Keep this
manual for future reference. Find a suitable space to
assemble your new Planter Box.
You need at least 18" x 20" (46 x 51cm) for the finished
product. A flat and firm area (like a garage floor or flat
yard space) is perfect! The only tool you may need is a
rubber mallet.
Important Notes
Small parts are included; we advise you to keep
them away from children and pets.
We also suggest having another person help you
assemble. Maximum Load Capacity: approximately
4 cu. ft. of soil
Subscribe at www.everbloom-garden.com
for extra savings and upgrading information!
Everbloom-Garden.com
Questions or Comments?
Email us at service@everbloom-garden.com
Model# E211719 / E211719G
Dimensions 17" L x 19" W x 21" H
1
Advertisement
Related Manuals for Everbloom E211719
Summary of Contents for Everbloom E211719
- Page 1 Planter Box Cornerstone Installation Guide Thank You! Model# E211719 / E211719G Dimensions 17" L x 19" W x 21" H You’re only a few steps away from your perfect vegetable garden or elevated planter. We hope you enjoy! Before You Start Please read the instructions carefully to familiarize yourself with every detail and step involved.
-
Page 2: Parts List
Parts List Planter Box Cornerstone - 17" L x 19" W x 21" H Left Corner Right Corner Short Short Bottom Post Post Board A Board B Board 420mm 420mm 460mm Bottom Bottom Post Cap Garden Bed Liner + 2pc replacement... - Page 3 Assembly Planter Box Cornerstone - 17" L x 19" W x 21" H Four depths are available by changing the sequence of the boards and position of the bottom boards, as shown in below images. You can choose according to different needs first. * For depth of 16.9”...
- Page 4 Assembly Planter Box Cornerstone - 17" L x 19" W x 21" H For the deepest planting depth of 16.9”, please follow steps below. For depth of 10”, the assembly methods are similar, just pay attention to the sequence of the boards and position of the bottom boards, please refer to page 3.
- Page 5 Assembly Planter Box Cornerstone - 17" L x 19" W x 21" H Slide another short board B into the other two corner brackets from above, as shown in Image 5. IMAGE 5 Right Corner Post Left Corner Post Left Corner Post Right...
- Page 6 Assembly Planter Box Cornerstone - 17" L x 19" W x 21" H With the help of another person holding the 2 assembled parts, slide another short boards B into the brackets from above. Make sure that one board goes straight to the bottom, while the other one stays in the middle of the way (don’t push it to the bottom), with the top edge between the 5th and 6th holes of the post.
- Page 7 Assembly Planter Box Cornerstone - 17" L x 19" W x 21" H Put the bottom boards on lower slots of short boards B. Make sure the 2 ends of these bottom boards go into the lower slots and rest in them with enough contact as shown in Image 7. Adjust the height of the higher short board B slightly to hold these bottom boards if necessary.
- Page 8 Assembly Planter Box Cornerstone - 17" L x 19" W x 21" H Push down the higher short board B to the bottom, as shown in Image 8. IMAGE 8 Short Board B Short Board B...
- Page 9 Assembly Elevated Planter Box - 17" L x 19" W x 28" H Slide the remaining boards into place, as shown in Image 9. Now you get an planter box cornerstone with 10” planting depth. Then, go to page 15, and follow the steps afterwards. Note: If you want to add trellis kit onto this bed, please assemble the extension connectors before this step, to avoid disassembling the boards later.
- Page 10 Assembly Planter Box Cornerstone - 17" L x 19" W x 21" H For the planting depth of 14.4”, please follow steps below. For depth of 7.5”, the assembly methods are similar, just pay attention to the sequence of the boards and position of the bottom boards, please refer to page 3.
- Page 11 Assembly Planter Box Cornerstone - 17" L x 19" W x 21" H Slide another short board B into the other two corner brackets from above, as shown in Image 5a. IMAGE 5a Right Corner Post Left Corner Post Left Corner Post Right...
- Page 12 Assembly Planter Box Cornerstone - 17" L x 19" W x 21" H With the help of another person holding the 2 assembled parts, slide another two short boards B into the brackets from above to the bottom, as shown in Image 6a. IMAGE 6a Short Board B...
- Page 13 Assembly Planter Box Cornerstone - 17" L x 19" W x 21" H Put the bottom boards on the short boards B, as shown in Image 7a. IMAGE 7a Bottom Board Short Board B...
- Page 14 Assembly Planter Box Cornerstone - 17" L x 19" W x 21" H Slide the remaining boards into place, as shown in Image 8a. Now you get a planter box cornerstone with 7.5” planting depth. Note: If you want to add trellis kit onto this planter box, please assemble the extension connectors before this step, to avoid disassembling the boards later.
- Page 15 Assembly Planter Box Cornerstone - 17" L x 19" W x 21" H If necessary, use your rubber mallet to ensure the boards are tightly in place. Cover the brackets with the 4 end caps, as shown in Image 10. IMAGE 10 Rubber Mallet...
- Page 16 Assembly Planter Box Cornerstone - 17" L x 19" W x 21" H Unfold the liner and cover the bottom of the garden bed, as shown in Image 11 and Image 12. IMAGE 11 Garden Bed Liner IMAGE 12...
- Page 17 Note Planter Box Cornerstone - 17" L x 19" W x 21" H Sometimes there might be a misalignment of the Corner Posts as shown in Image 13 and Image 14, which may result in difficulty of sliding boards into the brackets. Please adjust them to the right position so that they are parallel to each other, and perpendicular to the ground.
- Page 18 Bloom On. Everbloom-Garden.com US Patent Pending Subscribe at www.everbloom-garden.com for extra savings and upgrading information! Distributed by: Dynaforge Trading LLC St. Paul, MN55101 Email: service@everbloom-garden.com...
