Trough Planter Box
Installation Guide
Thank You!
You're only a few steps away from your perfect vegetable
garden or elevated planter. We hope you enjoy!
Before You Start
Please read the instructions carefully to familiarize
yourself with every detail and step involved. Keep this
manual for future reference. Find a suitable space to
assemble your new Trough Planter Box.
You need at least 37" x 13" (94 x 33cm) for the finished
product. A flat and firm area (like a garage floor or flat
yard space) is perfect! The only tool you may need is a
rubber mallet.
Important Notes
Small parts are included; we advise you to keep
them away from children and pets.
We also suggest having another person help you
assemble. Maximum Load Capacity: approximately
3 cu. ft. of soil
Subscribe at www.everbloom-garden.com
for extra savings and upgrading information!
Everbloom-Garden.com
Questions or Comments?
Email us at service@everbloom-garden.com
Model# E143612 / E143612G
Dimensions 36" L x 12" W x 14" H
1
Advertisement
Related Manuals for Everbloom E143612
Summary of Contents for Everbloom E143612
- Page 1 Trough Planter Box Installation Guide Thank You! Model# E143612 / E143612G Dimensions 36" L x 12" W x 14" H You’re only a few steps away from your perfect vegetable garden or elevated planter. We hope you enjoy! Before You Start Please read the instructions carefully to familiarize yourself with every detail and step involved.
-
Page 2: Parts List
Parts List Trough Planter Box - 36" L x 12" W x 14" H Left Corner Right Corner Long Long Support Short Short Bottom Post Post Board Board Board A Board B Board 240mm 240mm Bottom Bottom 420mm 900mm 900mm Post Cap Garden Bed Liner... - Page 3 Assembly Trough Planter Box - 36" L x 12" W x 14" H There are 2 different assembly methods providing 2 different planting depths: 10” (as shown in Image 1) and 7.5” (as shown in Image 2). * For deeper planting depth of 10”, please follow steps from page 4. * For easier but shallower planting depth of 7.5”, please go to page 10.
- Page 4 Assembly Trough Planter Box - 36" L x 12" W x 14" H Start by making sure each corner post is oriented correctly, as shown in Image 3. Slide one short board B into the corner brackets from above. Note: The short boards need to be placed in the inward “U” shape of the brackets, as shown in Image 4. IMAGE 3 IMAGE 4 Short...
- Page 5 Assembly Trough Planter Box - 36" L x 12" W x 14" H Slide another short board B into the other two corner brackets from above, as shown in Image 5. IMAGE 5 Right Corner Post Left Corner Post Left Corner Post Short Board B...
- Page 6 Assembly Trough Planter Box - 36" L x 12" W x 14" H With the help of another person holding the 2 assembled parts, slide the 2 long supporting boards into the brackets from above. Make sure that one support board goes straight to the bottom, while the other one stays in the middle of the way (don’t push to the bottom), with the top edge between the 2nd and 3rd holes of the post.
- Page 7 Assembly Trough Planter Box - 36" L x 12" W x 14" H Put the bottom boards on lower slots of long support boards. Make sure the 2 ends of these bottom boards go into the lower slots and rest in them with enough contact as shown in Image 7. Adjust the height of the higher long support board slightly to hold these bottom boards if necessary.
- Page 8 Assembly Trough Planter Box - 36" L x 12" W x 14" H Push down the higher long support board to the bottom, as shown in Image 8. IMAGE 8 Long Support Board Long Support Board...
- Page 9 Assembly Trough Planter Box - 36" L x 12" W x 14" H Slide the remaining boards into place, as shown in Image 9. Now you get an trough planter box with 10” planting depth. Then, go to page 15, and follow the steps afterwards. Note: If you want to add trellis kit onto this bed, please assemble the extension connectors before this step, to avoid disassembling the boards later.
- Page 10 Assembly Trough Planter Box - 36" L x 12" W x 14" H Start by making sure each corner post is oriented correctly, as shown in Image 3a. Slide one short board B into the corner brackets from above. Note: The short boards need to be placed in the inward “U” shape of the brackets, as shown in Image 4a. IMAGE 3a IMAGE 4a Short...
- Page 11 Assembly Trough Planter Box - 36" L x 12" W x 14" H Slide another short board B into the other two corner brackets from above, as shown in Image 5a. IMAGE 5a Right Corner Post Left Corner Post Left Corner Post Short Board B...
- Page 12 Assembly Trough Planter Box - 36" L x 12" W x 14" H With the help of another person holding the 2 assembled parts, slide the 2 long support boards into the brackets from above, as shown in Image 6a. IMAGE 6a Long Support Board...
- Page 13 Assembly Trough Planter Box - 36" L x 12" W x 14" H Put the bottom boards on the long support boards, as shown in Image 7a. IMAGE 7a Bottom Board Long Support Board...
- Page 14 Assembly Trough Planter Box - 36" L x 12" W x 14" H Slide the remaining boards into place, as shown in Image 8a. Now you get an trough planter box with 7.5” planting depth. Note: If you want to add trellis kit onto this bed, please assemble the extension connectors before this step, to avoid disassembling the boards later.
- Page 15 Assembly Trough Planter Box - 36" L x 12" W x 14" H If necessary, use your rubber mallet to ensure the boards are tightly in place. Cover the brackets with the 4 end caps, as shown in Image 10. IMAGE 10 Rubber Post Cap...
- Page 16 Assembly Trough Planter Box - 36" L x 12" W x 14" H Unfold the liner and cover the bottom of the garden bed, as shown in Image 11 and Image 12. IMAGE 11 Garden Bed Liner IMAGE 12...
- Page 17 Note Trough Planter Box - 36" L x 12" W x 14" H Sometimes there might be a misalignment of the Corner Posts as shown in Image 13 and Image 14, which may result in difficulty of sliding boards into the brackets. Please adjust them to the right position so that they are parallel to each other, and perpendicular to the ground.
- Page 18 Bloom On. Everbloom-Garden.com US Patent Pending Subscribe at www.everbloom-garden.com for extra savings and upgrading information! Distributed by: Dynaforge Trading LLC St. Paul, MN55101 Email: service@everbloom-garden.com...
