Arkon RoadVise Ultra KNRM9A Manual

KNRM9A | RoadVise ®
SP25MM9A
APMAMPS25MM
Install the 25mm AMPS Adapter Ball Plate to the RoadVise® Ultra
Phone Holder
Locate the packaging with the AMPS ball adapter plate and the phone
holder. Then, insert the four mounting screws through the AMPS
4-hole ball adapter plate and into the phone holder. Finally, secure the
screws tightly.
WARNING
CHOKING HAZARD - Keep out of reach from children under 8 yrs. as they can choke or suffocate on parts included with this system
WARNING
Arkon ® is not responsible for any damages caused to your device or yourself due to the installation or use of this mount. Do not install Arkon
of vehicles. Arkon ® assumes no responsibility or liability for injury or death as a result of failure to install in a safe location. Arkon
product, or people due to the installation or use of this product.
Ultra™ Motorcycle Phone Mount with Angled Mirror/Pinch Bolt Adapter
RVKNAMPS
SP-RM250
Includes:
1 – RoadVise ®
2 – Foam Padding
4 – Screws
(M4 x 12mm)
1 – 25mm Metal AMPS 4-Hole Adapter
1 – 25mm Robust Shaft Arm
1 – 25mm Ball to 9mm Angled Bolt Head Adapter
Important: Clean the application surface and make sure it is free of dirt,
dust, and grease before installing the mounting hardware.
Assemble the Components
Loosen the shaft arm knob by turning it counter-clockwise to
allow the ball adapters to insert into the shaft arm. Next, insert
the ball mounts to either end of the shaft arm and turn the knob
clockwise to tighten.
USA (800) 841-0884
INT'L (626) 254-9005
Monday - Friday 9 am - 5 pm PST
Ultra Phone Holder
(RVKNAMPS)
(APMAMPS25MM)
(SP-RM250)
® products near areas that intefere with operation
® is not responsible for any damages caused to vehicles,
arkon.com
Designed in USA
©Arkon Resources, Inc.
rev.022124
(SP25MM9A)
Need assistance?
Scan to email our
Arkon® customer
service team.
