MERIT DELUXE
2000
OPERATIONS
SERVICE
CARE
Warnings and Grounding Inshuctions
2
Operation
3
4
Maintenance
Troubleshooting
6
Pad Driver Assembly
Main Cover Assembly
8
Caster Assembly
10
Handle Assembly (upper)
12
14
Motor and Brush Assembly
Lower Handle Assembly
16
Motor Wiring Diagrams
18
Diagrams
I9
Wiring
we-
98190 01/12/01
AF 115V
U l t r a H i g h S p e e d E l e c t r i c B u r n i s h e r s
INDUSTRIES, INC.,
1351 W.
Stanford
Ave., Englewood CO 80110 USA *303-762-180O*FAX
Page
of
20
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MERIT DELUXE 2000 F and is the answer not in the manual?

Questions and answers

Related Manuals for Windsor MERIT DELUXE 2000 F

Summary of Contents for Windsor MERIT DELUXE 2000 F

  • Page 1 MERIT DELUXE AF 115V 2000 Page U l t r a H i g h S p e e d E l e c t r i c B u r n i s h e r s OPERATIONS SERVICE CARE Warnings and Grounding Inshuctions Operation...
  • Page 2 Record model and serial number located on data label. Refer to these numbers when Tab For Grounding Adaptor calling Windsor dealer for parts or service. screw MODEL : ADAPTOR Fig. 6 SERIAL NO. : Fig. C PURCHASE DATE :...

  • Page 3: Operation

    Page 3 of MERIT DELUXE AF 115V 2000 OPERATION CONTROLS machines and should be operated in a straight line -forward and rearward- not side to side as low speed polishers are operated. this machine only for dry polishing, DO NOT USE FOR WET FLOOR SCRUBBING OR POLISHING WITH WET SPRAY BUFF LIQUIDS.
  • Page 4 MERIT DELUXE AF 1 15V Page 4 of 20 2000 FILTER CARTRIDGE DAILY MAINTENANCE: Warning: (At the end of each working day): Never operate this machine without the filter or filter cover place. 1 .) Inspect power cord for wear. To prevent electrical The filter (pn 34212) is accessed using the latch at the shock replace cords with frayed or cracked insulation im- front of the cover.

  • Page 5: Troubleshooting Chart

    Motor worn out Contact Windsor Techrucal Service Representabve Circuit breaker Faulty circuit breaker Test circuit breaker for COnbflUity. Replace cirmit tripping breaker if nec-...

  • Page 6: Pad Driver Assembly

    MERIT DELUXE AF 1 15V 2000 Page 6 of PAD DRIVER ASSEMBLY Frame Assembl...
  • Page 7 MERIT DELUXE AF 115V 2000 Page 7 of PAD DRIVER ASSEMBLY Parts List From Pad Holder, Center Lock 41161 PHTR PLTD 70361 1 / 4 x 1/2 PHTR 10-32 x 3/4 PHTR 70383 Disc Hub, Flex 41187 Pad Driver 66142 Seal, Shroud Clamp, Washer,...
  • Page 8 Page 8 of MERIT DELUXE 2000 AF 115V...
  • Page 9 MERIT DELUXE AF 115V 2000 Page 9 of MAIN COVER ASSEMBLY Parts Serial From 35117 Gasket, Filter 70351 Cover, Caster Bracket Spacer, 89059 Washer, 1/4 Flat Grade 87120 1.75 HHMS 70105 87139 Washer, 3/16 Flat USS PFHTC 70012 Latch. F i l m i c Filter Cover 51179 Cover, Filter Nut, 6-32 wlStar Washer...
  • Page 10 MERIT DELUXE 2000 AF Page 10 of Models Blue thread locking adhesive...
  • Page 11 MERIT DELUXE AF 115V 2000 Page 11 of CASTER ASSEMBLY PARTS LIST...

  • Page 12: Handle Assembly

    MERIT DELUXE AF 115V 2000 Page HANDLE ASSEMBLY Terminal Block Asm...

  • Page 13: Handle Assembly Parts List

    2000 AF MERIT DELUXE 1 15V Page 13 of HANDLE ASSEMBLY PARTS LIST 98190 1/12/01...
  • Page 14 MERIT DELUXE AF 115V 2000 Page 14 of MOTOR AND BRUSH ASSEMBfY To tighten remove the belt; Remove belt guard, item and loosen the motor additional information see 21. For...
  • Page 15 MERIT DELUXE 2000 AF 115V Page 15 of MOTOR AND BRUSH ASSEMBLY Parts LIst From Ring, 67162 Bearing, 09030 2.00 Pulley, Pad (standard) 64072 Pulley, Pad models) 64065 09033 Bearing, 1.00 Axle, Pad Driver 03049 Frame, Main 34205 Plate, Axle Mounting 62241 Scr, HHTF pltd.
  • Page 16 MERIT DELUXE AF 115V 2000 Page 16 of LOWER HANDLE ASSEMBLY POSITION...
  • Page 17 MERIT DELUXE AF 115V 2000 Page 17 of LOWER HANDU ASSEMBLY Parts List Notes: From Spacer, .75 x .39 x .25 HDPE Axle, 38 03059 Transport Wheel Wheel, 5 x 1 x 3 / 8 Transport Scr, 10-32 x 112 PHMS 70088 87016 Washer, #10 Star...

  • Page 18: Motor Wiring Diagrams

    MERIT DELUXE AF 115V 2000 Page 18 of MOTOR WIRING DIAGRAMS Motors Black Black Black White Attached to frame and ground wire. 98190 7/1/97...
  • Page 19 MERIT DELUXE AF 115V 2000 Page 19 of WIRING DlAGRAMS...

  • Page 20: Limited Warranty

    7.electrical components exposed to moisture. If difficulty develops during the warranty penod, contact the authorized Windsor Agent from whom the product was purchased. Windsor, Inc. may elect to require the return of components to validate a claim. Any defective part to returned must be shipped freight pre-paid to an authonzed Windsor Distributor/Service Center or to the Windsor factory.
