Reference Manual
PANEL Computer
PT-M17SB-2500 Series
CONTENTS
Introduction .......................................................... 4
Safety Precautions .............................................. 12
Product Nomenclature and Function .............. 18
Hardware Setup .................................................. 30
BIOS Setup .......................................................... 41
Appendix ............................................................. 66
List of Optional Products ................................... 84
Customer Support and Inquiry ......................... 88
Advertisement
Table of Contents
Related Manuals for Contec PT-M17SB-2500 Series
Summary of Contents for Contec PT-M17SB-2500 Series
- Page 1 Reference Manual PANEL Computer PT-M17SB-2500 Series CONTENTS Introduction ............4 Safety Precautions ..........12 Product Nomenclature and Function ....18 Hardware Setup ..........30 BIOS Setup ............41 Appendix ............. 66 List of Optional Products ........84 Customer Support and Inquiry ......88...
-
Page 2: Table Of Contents
Table of Contents Introduction ..............4 1. Related Manuals ..........................5 2. About the Product ..........................6 3. Product Lineup ........................... 7 4. Features .............................. 8 5. Supported OS ............................. 9 6. Product Configuration List ......................10 Safety Precautions ............12 1. - Page 3 Table of Contents BIOS Setup .................. 41 1. Introduction ............................42 1. Starting Setup ..........................42 2. Using Setup ..........................43 3. Getting Help ..........................43 4. In Case of Problems ........................43 5. A Final Note About Setup ......................43 2.
-
Page 4: Introduction
Introduction This section provides necessary information of the product such as the outline, bundled items and manuals before actual use. - 4 -... -
Page 5: Related Manuals
— — Introduction PT-M17SB-2500 Series Reference Guide 1.Related Manuals The manuals related to the product are listed below. Read them as necessary along with this document. ◆ Must Read the Following Manuals. Name Purpose Contents How to get Product Guide... -
Page 6: About The Product
— — Introduction PT-M17SB-2500 Series Reference Guide 2.About the Product This product is a high-performance embedded-type personal computer equipped with the 9 ® ® generation Intel Core™ and Celeron processor. Embedded-type chipset and CPU have been adopted. The use of readily available parts ensures the ease of the use of the product. -
Page 7: Product Lineup
— — Introduction PT-M17SB-2500 Series Reference Guide 3.Product Lineup The product has three models. Model Description PT-M17SB-2500-G604NA Intel® Core™ i7-9700TE 17-inch PCAP Touch DDR4 8GB Memory PT-M17SB-2500-G504NA Intel® Core™ i5-9500TE Windows 10 PT-M17SB-2500-G404NA Intel® Core™ i3-9100TE Windows 11 pro PT-M17SB-2500-G204NA Intel®... -
Page 8: Features
— — Introduction PT-M17SB-2500 Series Reference Guide 4.Features ◼ Compatible with Intel ® Coffee Lake-Refresh Platform This product is equipped with the 9 generation Intel® Core™ processor and greatly realizes lower-power consumption while ensuring fine performance of operation tasks and drawing. Adopting embedded-type CPU contributes to a stable supply. -
Page 9: Supported Os
— — Introduction PT-M17SB-2500 Series Reference Guide 5.Supported OS Windows® 10 IoT Enterprise LTSC 2019 64 bit Windows® 11 IoT Enterprise 23H2 64Bit For information about operating system version updates, please contact your authorized reseller. ⚫ - 9 -... -
Page 10: Product Configuration List
Screws for Attachment HDD (or SSD) Cable Clamp 1 Cable Clamp 2 Product Guide *1 The configuration and parts of this product are shown below. *2 The user manual for this product is available as a PDF file through CONTEC’s website. - 10 -... - Page 11 — — Introduction PT-M17SB-2500 Series Reference Guide Production Configuration Drawings Panel-PC USB removal The attachment DVI-analog RGB Power supply connector complete prevention fitting fittings conversion adapter Washer assembled Screws for attachment Cable clamp 1 Cable clamp 2 Product Guide Screw (M3x6)
-
Page 12: Safety Precautions
Safety Precautions Understand the following definitions and precautions to use the product safely. Never fail to read them before using the product. - 12 -... -
Page 13: Safety Information
— — Safety Information PT-M17SB-2500 Series Reference Guide 1.Safety Information This document provides safety information using the following symbols to prevent accidents resulting in injury or death and the destruction of equipment and resources. Understand the meanings of these labels to operate the equipment safely. -
Page 14: Handling Precautions
— — Safety Information PT-M17SB-2500 Series Reference Guide 2.Handling Precautions WARNING Always check that the power supply is turned off before connecting or disconnecting power ⚫ cables. Do not modify the product. ⚫ Always turn off the power before inserting or removing circuit boards or cables. - Page 15 To prevent corruption of files, always shutdown the OS before turning off this product. ⚫ CONTEC reserves the right to refuse to service a product modified by the user. ⚫ In the event of failure or abnormality (foul smells or excessive heat generation), unplug the ⚫...
-
Page 16: Fcc Part 15 Class A Notice
— — Safety Information PT-M17SB-2500 Series Reference Guide 1. FCC PART 15 Class A Notice NOTE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 17: Security Warning
— — Safety Information PT-M17SB-2500 Series Reference Guide 3.Security Warning When connecting to the network, be aware of security-related problems. See the examples of Security measures below and set up the product properly along with the network devices. 1. Information security risks Unauthorized access from the outside through a network could cause the system halt, data ⚫... -
Page 18: Product Nomenclature And Function
Product Nomenclature and Function This section describes product component names and their functions, pin assignment of each connector. - 18 -... -
Page 19: Nomenclature Of Product Components
— — Product Nomenclature and Function PT-M17SB-2500 Series Reference Guide 1.Nomenclature of Product Components Component names of the product are shown in the figure below. ◆ Front View DISPLAY PORT LAN A USB3.2 POWER SW LAN B USB2.0 LINE OUT... - Page 20 — — Product Nomenclature and Function PT-M17SB-2500 Series Reference Guide Name Function Front POWER LED Power ON indicator LED STATUS LED Status LED Drive ACCESS LED Disk access indicator LED DC-IN DC power input connector POWER SW Power switch MIC IN Mic in (∅3.5 PHONE JACK)
-
Page 21: Description Of Product Components
ON (Red) You can control the behavior of LED from the used application. *1 *1: API that controls Status LED is available. For more information, visit CONTEC’s website. 2 DC Power Input Connector: DC-IN To supply the power, always use the power supply listed below. -
Page 22: Power Sw
— — Product Nomenclature and Function PT-M17SB-2500 Series Reference Guide 3. Power SW Power SW is provided 4. LINE OUT Interface: LINE OUT The product is equipped with a connector for line output. As such, headphones or an amplified speaker can be connected. - Page 23 — — Product Nomenclature and Function PT-M17SB-2500 Series Reference Guide 6. Serial-ATA: SATA 1, SATA 2 The product has two ports of serial ATA 3.0 compliant controllers. Connector used on the product SATA connector Pin No. Signal name Pin No.
-
Page 24: Dvi-I Interface
7. DVI-I Interface A DVI-I interface is provided. A CRT display (or a 15-pin D-SUB CRT when the included DVI–Analog RGB conversion adapter is used) or a flat-panel display from CONTEC can be connected. The connector name is DVI (DVI-I 29 pin). - Page 25 — — Product Nomenclature and Function PT-M17SB-2500 Series Reference Guide Connector type DVI-I Analog RGB signals Pin No. Signal name Pin No. Signal name GREEN BLUE N.C. N.C. DDC DATA HSYNC VSYNC DDC CLK CAUTION If the OS is booted without connecting the display cable to the DVI interface, and then the ⚫...
-
Page 26: Display Port Interface
— — Product Nomenclature and Function PT-M17SB-2500 Series Reference Guide 8. Display Port Interface A display port interface is provided. As such, a display equipped with a Display Port can be connected. Connector used on the product Display Port 20 Pin... -
Page 27: Usb3.2 (Gen 2×1) Port
— — Product Nomenclature and Function PT-M17SB-2500 Series Reference Guide 9. USB3.2 (Gen 2×1) Port This product is equipped with 4 channels for USB 3.2 TYPE-A interface. USB3.2 Connector Signal Name USB_VCC DATA- DATA+ USB_GND SSRX- SSRX+ USB_GND SSTX- SSTX+ 10. -
Page 28: Gigabit-Ethernet
— — Product Nomenclature and Function PT-M17SB-2500 Series Reference Guide 11. Gigabit-Ethernet This product is equipped with 2 ports for gigabit. Network Type: 1000 BASE-T/ 100 BASE-TX/ 10 BASE-T Transmission Speed : 1000M/ 100M/ 10M bps Max. network path length: 100m/ segment Controller: LAN A: LAN-A: Intel ®... -
Page 29: Serial Port Interface: Serial A, B, C, D
— — Product Nomenclature and Function PT-M17SB-2500 Series Reference Guide 12. Serial Port Interface: Serial A, B, C, D The product has 3 channels of RS-232C and 1 channel of RS-232C/422/485 compliant serial ports supporting up to a baud rate of 115,200bps with a 16-byte transmission-dedicated data buffer and a 16-byte reception-dedicated data buffer. - Page 30 — — Product Nomenclature and Function PT-M17SB-2500 Series Reference Guide Serial A port connector Connector used on the product 9-pin D-SUB (MALE) Pin No. RS-232C RS-422 RS-485 DATA- DATA+ RTS- RTS+ CTS+ CTS- Serial B, C, D port connector Connector used on the product 9-pin D-SUB (MALE) Pin No.
-
Page 31: Hardware Setup
Hardware Setup This section describes how to install, connect, and set up the product. - 31 -... -
Page 32: Before Using The Product For The First Time
— — Hardware Setup PT-M17SB-2500 Series Reference Guide 1.Before Using the Product for the First Time Follow the next steps to set up this product: STEP1 By referring to the information in this section, install, connect and set up this product. -
Page 33: Hardware Setup
— — Hardware Setup PT-M17SB-2500 Series Reference Guide 2.Hardware Setup Before you start, be sure that the power is turned off. ⚫ Remove only those screws that are explained. Do not move any other screws. ⚫ You can equip the product with slot-in type 2.5-inch SATA storage. -
Page 34: Attaching The Fg
— — Hardware Setup PT-M17SB-2500 Series Reference Guide 2. Attaching the FG Use screws to attach the FG. CAUTION The FG pin of this product is connected to the GND signal of the DC power connector (DC-IN). ⚫ Note that the connection cannot be cut off. -
Page 35: Fastening The Cable
— — Hardware Setup PT-M17SB-2500 Series Reference Guide 3. Fastening the Cable This produce comes with clamps for fixing cables. To Fasten the USB cable: 1) The system unit has a hole for attaching cable clamp to USB removal prevention fitting. Using a cable clamp for a cable with lock-less connector, such as the USB cable, prevents the connector from being unplugged. - Page 36 — — Hardware Setup PT-M17SB-2500 Series Reference Guide 2) The photo below shows an example of using a cable clamp. Fix the cable with a clamp without applying stress to the connector. - 36 -...
-
Page 37: Mounting
— — Hardware Setup PT-M17SB-2500 Series Reference Guide 4. Mounting This product supports both panel mount and VESA mount (75x75mm or 100x100mm.) Before mounting installation, please confirm below three sections. 1) Cut out a panel according to the following dimensions to mount the main unit. - Page 38 — — Hardware Setup PT-M17SB-2500 Series Reference Guide 3) Hold the attachment fitting from the inside of the panel. CAUTION Screw holes may be damaged if screws are tightened with a torque greater than the specified ⚫ torque. The specified tightening torque is 5 - 6kgf·cm.
- Page 39 — — Hardware Setup PT-M17SB-2500 Series Reference Guide Examples are as follows: When use VESA standard 75mm mounting holes, the main body has mounting holes according to VESA standard 75mm. When using a VESA standard 75mm stand or the like, attach it as shown the following figure.
-
Page 40: Installation Requirements
— — Hardware Setup PT-M17SB-2500 Series Reference Guide 5. Installation Requirements Installation Angle Be sure that the operating temperature is within the range specified in the installation environment requirement by making space between the product and the device that generates hear or exhaust air. - Page 41 — — Hardware Setup PT-M17SB-2500 Series Reference Guide Installation Distance CAUTION Unless the internal temperature is adjustable by equipment such as air conditioner, do not ⚫ install this product into the fully sealed space. Troubles, such as operational malfunctions, could be occurred by the temperature rises caused by long-term usage.
-
Page 42: Bios Setup
BIOS Setup This section describes AMI’s Setup program built into the FLASH ROM BIOS. - 42 -... -
Page 43: Introduction
— — BIOS Setup PT-M17SB-2500 Series Reference Guide 1.Introduction This chapter discusses American Megatrends’ (AMI) Setup program built into the FLASH ROM BIOS. The Setup program allows users to modify the basic system configuration. This special information is then stored in FLASH ROM so that it retains the Setup information when the power is turned off. -
Page 44: Using Setup
— — BIOS Setup PT-M17SB-2500 Series Reference Guide 2. Using Setup In general, you use the arrow keys to highlight items, press <Enter> to select, use the PageUp and PageDown keys to change entries, press <F1> for help and press <Esc> to quit. The following table provides more detail about how to navigate in the Setup program using the keyboard. -
Page 45: Main Menu
— — BIOS Setup PT-M17SB-2500 Series Reference Guide 2.Main Menu When the setup program (Aptio Startup Utility) is started, the main menu will be displayed. Navigate through the various tabs by pressing the right and left arrow keys. - 45 -... -
Page 46: Setup Items
— — BIOS Setup PT-M17SB-2500 Series Reference Guide 1. Setup Items The selectable tabs are as follows. Main View the basic system structure and configure the language settings and the date and time settings. Advanced Specify the detailed functions that can be set on the system used. -
Page 47: Main
— — BIOS Setup PT-M17SB-2500 Series Reference Guide 3.Main View the basic system structure. The following items are displayed. Indication item of the main menu Item Indication Example Explanation Project Version M21WBT x.xx x64 Displays the BIOS version. Build Date and Time... -
Page 48: Advanced
— — BIOS Setup PT-M17SB-2500 Series Reference Guide 4.Advanced Specify the detailed system functions. The following items are available. CPU Configuration Configure the CPU settings. SATA Configuration Configure the SATA controller settings. PCH-FW Configuration Configure the management engine technology parameters. - Page 49 — — BIOS Setup PT-M17SB-2500 Series Reference Guide 1. CPU Configuration CPU Configuration Item Options Description Enabled Intel (VMX) Virtualization Technology Do not change this setting. Disabled Active Processor Cores Do not change this setting. Max Battery Max Non-Turbo Performance Boot performance mode Do not change this setting.
-
Page 50: Sata Configuration
— — BIOS Setup PT-M17SB-2500 Series Reference Guide 2. SATA Configuration SATA Configuration Item Options Description Enabled Configure the SATA SATA Controller(s) Disable device. Determines how AHCI SATA Mode Selection SATA controller(s) Intel RST Premium with Intel Optane System Acceleration operate. - Page 51 — — BIOS Setup PT-M17SB-2500 Series Reference Guide RAID setting SATA Mode selection change to Intel RST Premium - 51 -...
-
Page 52: Pch-Fw Configuration
— — BIOS Setup PT-M17SB-2500 Series Reference Guide 3. PCH-FW Configuration PCH-FW Configuration Item Options Description Enabled ME State Do not change this setting. Disabled Enabled Manageability Features State Do not change this setting. Disabled - 52 -... -
Page 53: Trusted Configuration
— — BIOS Setup PT-M17SB-2500 Series Reference Guide 4. TRUSTED Configuration TRUSTED Configuration Item Options Description Enable TPM 2.0 Support Do not change this setting. Disable - 53 -... -
Page 54: Acpi Setting
— — BIOS Setup PT-M17SB-2500 Series Reference Guide 5. ACPI Setting ACPI Setting Item Options Description Enabled Enable Hibernation Configure the Hibernation settings Disabled Suspend Disabled ACPI Sleep State Configure the Sleep State settings S3 (Suspend to RAM) RTC Wake Settings... -
Page 55: Smart Setting
— — BIOS Setup PT-M17SB-2500 Series Reference Guide 6. SMART Setting ACPI Setting Item Options Description Enabled Run SMART Self Test on all HDDs during SMART Self Test Disabled POST - 55 -... -
Page 56: Super Io Configuration
— — BIOS Setup PT-M17SB-2500 Series Reference Guide 7. Super IO Configuration Super IO Configuration Item Options Description Serial Port 1 Configuration Refer to Serial Port 1 Configuration Serial Port 2 Configuration Refer to Serial Port 2 Configuration Serial Port 3 Configuration... - Page 57 — — BIOS Setup PT-M17SB-2500 Series Reference Guide Serial Port 2 Configuration Item Options Description Enabled Configure the operation settings for serial Serial Port Disabled port 2 Serial Port 3 Configuration Item Options Description Enabled Configure the operation settings for serial...
-
Page 58: Hardware Monitor
— — BIOS Setup PT-M17SB-2500 Series Reference Guide 8. Hardware Monitor View hardware monitor information such as the CPU temperature. Smart FAN Mode Configuration Item Options Description PWM Manual Mode System Smart FAN Mode Do not change this setting. Thermal Cruise Mode... -
Page 59: Usb Configuration
— — BIOS Setup PT-M17SB-2500 Series Reference Guide 9. USB Configuration USB Configuration Item Options Description Enabled Legacy USB Support Disabled Do not change this setting. Auto Enabled XHCI Hand-off Do not change this setting. Disabled USB Mass Storage Enabled Do not change this setting. -
Page 60: Chipset
— — BIOS Setup PT-M17SB-2500 Series Reference Guide 5.Chipset The following items are available System Agent (SA) Configuration Configure system agent (SA) settings. PCH-IO Configuration Configure the HD Audio subsystem. - 60 -... - Page 61 — — BIOS Setup PT-M17SB-2500 Series Reference Guide 1. System Agent (SA) Configuration Graphic Configuration Item Options Description Auto IGFX Primary Display Do not change this setting. Auto Internal Graphics Do not change this setting. Enabled Disabled GTT Size Do not change this setting.
- Page 62 — — BIOS Setup PT-M17SB-2500 Series Reference Guide Item Options Description DVMT Pre-Allocated Do not change this setting. 32M/F7 128M DVMT Total Gfx Mem 256M Do not change this setting. Enabled PAVP Enable Do not change this setting. Disabled - 62 -...
-
Page 63: Pch-Io Configuration
— — BIOS Setup PT-M17SB-2500 Series Reference Guide 2. PCH-IO Configuration Configure how memory will be used when using the graphic function. Leave these settings as configured before shipment. PCH-IO Configuration Item Options Description Enabled HD Audio Do not change this setting. -
Page 64: Security
— — BIOS Setup PT-M17SB-2500 Series Reference Guide 6.Security Administrator Password Set the Administrator Password. Press Enter to display the following screen for entering the password. Administrator Password Create New Password **** Confirm New Password [ **** Enter a password at least 3 characters long twice. -
Page 65: Boot Configuration
— — BIOS Setup PT-M17SB-2500 Series Reference Guide 7.Boot Configuration Configurate the settings boot devices and other devices PCH-IO Configuration Item Options Description Set the standby time for BIOS Setup <DEL> Setup Prompt Timeout or <F2> input. Unit : [second]... -
Page 66: Save And Exit
— — BIOS Setup PT-M17SB-2500 Series Reference Guide 8.Save and Exit Load/ Save setup items and exit the setup menu. - 66 -... -
Page 67: Appendix
Appendix This section lists the specifications and the physical dimensions of the product, and the details of model name. - 67 -... -
Page 68: System Reference
— — Appendix PT-M17SB-2500 Series Reference Guide 1.System Reference 1. Specifications Model Name PT-M17SB-2500 Series Generation Coffee Lake Refresh Intel® Core™ i7-9700TE Processor Generation Coffee Lake Refresh Intel® Core™ i5-9500TE Processor Generation Coffee Lake Refresh Intel® Core™ i3-9100TE Processor Generation Coffee Lake Refresh Intel® Celeron® G4900T Processor Operation System Windows®... - Page 69 — — Appendix PT-M17SB-2500 Series Reference Guide Model Name PT-M17SB-2500 Series LCD Panel Display Type 17” SXGA Color TFT-LCD Panel Ratio Max. Resolution 1280 x 1024 Max. Color 16.7M (colors RGB 8-bits) Brightness 350 cd/m2 Viewing Angle 180° (H) x 180° (V)
-
Page 70: Display Optical Specification
— — Appendix PT-M17SB-2500 Series Reference Guide 2. Display Optical Specification CAUTION The above optical specification data shows optical characteristics of the liquid crystal in the ⚫ display; the data does not represent the actual view on the display or its viewing angles. -
Page 71: Power Management Features
— — Appendix PT-M17SB-2500 Series Reference Guide 3. Power Management Features - Support both ACPI (Advanced Configuration and Power Interface). - ACPI v2.0 compliant - Support hardware automatic wake-up 4. Power Requirements Your system requires a clean, steady power source for reliable performance of the high frequency CPU on the product, the quality of the power supply is even more important. -
Page 72: Physical Dimensions
— — Appendix PT-M17SB-2500 Series Reference Guide 2.Physical Dimensions All Dimensions shown in mm (millimeters.) - 72 -... -
Page 73: Post Codes
— — Appendix PT-M17SB-2500 Series Reference Guide 3.Post Codes Description POST (hex) < Security (SEC) phase > Power ON. The detection of the reset kind (Hard/Soft) Initialize the microcode load previous AP Initialize the microcode load previous North Bridge Initialize the microcode load previous South Bridge... - Page 74 — — Appendix PT-M17SB-2500 Series Reference Guide POST Description South Bridge runtime services installation CPU DXE installation start 64h - 67h CPU DXE installation start (Specific CPU module) PCI host bridge installation North Bridge DXE initialization starts North Bridge DXE SMM initialization starts...
- Page 75 — — Appendix PT-M17SB-2500 Series Reference Guide POST Description Legacy boot event Boot Service event ends Virtual address maps run-time settings begin. Virtual address maps of runtime configuration exit Legacy option ROM initialization System reset USB hot plug PCI bus hot plug...
-
Page 76: Serial I/O Address And Register Function
— — Appendix PT-M17SB-2500 Series Reference Guide 4.Serial I/O Address and Register Function The following table lists the I/O addresses in case of SERIAL A. I/O Port Addresses I/O address DLAB Read/Write Register Transmitter holding register 03F8H Receiver buffer register... - Page 77 — — Appendix PT-M17SB-2500 Series Reference Guide I/O address Description IER: Interrupt Enable Register [DLAB=0] 03F9H IIR: Interrupt Identification Register 03FAH LCR: Line Control Register 03FBH - 77 -...
- Page 78 — — Appendix PT-M17SB-2500 Series Reference Guide Description I/O address MCR: Modem Control Register 03FCH LSR: Line Status Register 03FDH MSR: Modem Status Register 03FEH SCR: Scratchpad Register This is an 8-bit, readable/writable register which is available to the 03FFH user to allow data to be saved temporarily.
- Page 79 — — Appendix PT-M17SB-2500 Series Reference Guide Baud Rate Settings A baud rate is set by software by dividing the clock input (1.8432MHz). The baud rate in terms of hardware can be set to a maximum of 115,200 bps for SERIAL Port. The baud rates available in practice depend on the operating environment (cable, software, etc.).
-
Page 80: Watch-Dog-Timer
— — Appendix PT-M17SB-2500 Series Reference Guide 5.Watch-Dog-Timer The watchdog timer serves as a safeguard against possible system lock-up in your industrial computer system. In most industrial environments, there are heavy equipment, generators, high- voltage power lines, or power drops that have adverse effects on your computer system. For instance, when a power drop occurs, it could cause the CPU to come to a halt state or enter into an infinite loop, resulting in a system lock-up. - Page 81 — — Appendix PT-M17SB-2500 Series Reference Guide Example programming The following example is written in Intel8086 assembly language. ;=============== ;<WDT Initial> ;=============== ;Enter the extended function mode MOV DX,2EH MOV AL,87H OUT DX,AL OUT DX,AL ;Select logical device WDT(number 8)
- Page 82 — — Appendix PT-M17SB-2500 Series Reference Guide MOV AL,00H OUT DX,AL ;Exit the extended function mode MOV DX,2EH MOV AL,AAH OUT DX,AL ;=============================== ;<WDT START: counter set and a start> ;=============================== ;Enter the extended function mode MOV DX,2EH MOV AL,87H...
- Page 83 — — Appendix PT-M17SB-2500 Series Reference Guide OUT DX,AL ;Exit the extended function mode MOV DX,2EH MOV AL,AAH OUT DX,AL ;============== ;<WDT STOP> ;============== ;Enter the extended function mode MOV DX,2EH MOV AL,87H OUT DX,AL OUT DX,AL ;Select logical device WDT(number 8)
- Page 84 — — Appendix PT-M17SB-2500 Series Reference Guide OUT DX,AL ;Exit the extended function mode MOV DX,2EH MOV AL,AAH OUT DX,AL CAUTION The timer’s intervals have a tolerance of ± 2 seconds. ⚫ - 84 -...
-
Page 85: Touch Panel Driver Installation
— — Appendix PT-M17SB-2500 Series Reference Guide 6. Touch Panel Driver installation Touch screen driver: HID_Install_Package_2.13.0.12823-forPCAP-190223-Release. After installation according to the prompts, the system wallpaper will display the driver "ICON" (The below picture shows the software tool showing the RS-232 Port detection corresponding. - Page 86 — — Appendix 1) Expand these display settings: After installing the touch screen driver, select the built-in screen in the tablet options Ready to use. - 86 -...
- Page 87 — — Appendix 2) Duplicate these display settings Same as step 1). After the function is normal, select "Repeat" from the tablet options to use it normally. - 87 -...
-
Page 88: List Of Optional Products
List of Optional Products This section lists optional items that can be used along with the product. - 88 -... -
Page 89: Optional Product
*2.5” HDD 1 or 2x 500GB to 2TB 2.5"HDD *2.5” SSD 1 or 2x 128GB to 2TB 2.5"SSD Visit the CONTEC website for the latest optional products. *Option will be available. Please contact your Field Sales Rep https://www.contec.com/ Download - 89 -... -
Page 90: Customer Support And Inquiry
Customer Support and Inquiry CONTEC provides the following support services for you to use CONTEC products more efficiently and comfortably. - 90 -... -
Page 91: Services
— — Customer Support and Inquiry PT-M17SB-2500 Series Reference Guide 1.Services CONTEC offers the useful information including product manuals that can be downloaded through the CONTEC website. Download https://www.contec.com/download/ You can download updated driver software, firmware, and differential manuals in several languages. Membership registration (myCONTEC) is required to use the services. - Page 92 No part of this document may be copied or reproduced in any form by any means without ⚫ prior written consent of CONTEC CO., LTD. CONTEC CO., LTD. makes no commitment to update or keep current the information contained ⚫ in this document.
- Page 93 3-9-31, Himesato, Nishiyodogawa-ku, Osaka 555-0025, Japan https://www.contec.com/ No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. PT-M17SB-2500 Series Reference Manual LXDG541 NA09934 ( [04102024] March 2024 Edition...
