Atdec AWM-A46H Installation Manual

AWM 460 Arm Heavy Duty
COMPONENT CHECKLIST
A
Monitor Arm
(x1)
IMPORTANT INFORMATION
! Please ensure this product is installed as per these installation instructions.
! Do not remove or throw away the plastic sleeve on the channel clamp and arm links.
! The manufacturer accepts no responsibility for incorrect installation.
! This product is compatible with Atdec AWM Series products except the Wall Channel products (including AWM-W6
and AWM-W35)
! Curved monitors, deep devices (such as all-in-one PCs), VESA mounted accessories (such as mini PC brackets and mounts),
and offset VESA locations exert additional leverage that can exceed the capacity of the mount even though the monitor
weight may be within the stated range. Please contact Atdec if you would like further information.
B
Heavy Duty Tilt Head
(x1) M4x25mm
C
Channel Clamp Spacer
(x1)
D E
Screw Screw Screw
M4x16mm M4x12mm
(x4) (x4) (x4)
G H
Security 4mm
(x4) screw Hex Key
(x4) (x1)
Installation Guide
AWM-A46H
REQUIRED TOOLS
• Phillips Head Screwdriver
F
WEIGHT RANGE
Flat Monitors
0 - 14kg
(0 - 31lbs)
Curved Monitors
0 - 12kg
(0 - 26.5lbs)
I
Monitor weight should be within the
weight range of all modular elements
that make up the complete monitor
mounting solution.
AWM-A46H Page 1 of 4
