2. Installation.

The AC/AC power supply must be installed by a qualified installer, holding the relevant certificates, required and
necessary in the particular country for connecting (interfering with) the 230 V AC systems and low-voltage installations.
Because the AC/AC power supply unit ( transformer) is designed for the continuous operation and is not
equipped with ON/OFF switch, the power supply line should have the appropriate overload protection. The user should be
informed how to disconnect the power supply AC/AC unit from the mains (usually be means of the separate fuse in the
fuse-box). The power supply installation should conform to the applicable standards and law.
The AC/AC power supply should be installed indoors (controls cabinets, casings), where air humidity
is normal (RH=90% max. without condensation) and temperature in the range of -10°C to +40°C.
Caution!
All service works inside the housing must be carried out with 230V/AC supply
1. Mount the AC/AC power supply with TS35 installation bus (DIN 46277 B1).
2. Supply conductors ~230V should be connected to 230V / AC L-N terminals of power supply AC/AC.
4. Connect the output power supply AC/AC (transformer) to a device, using installed cables
Remarks: If necessary, make other connections required for the correct type of system / device.
5. If necessary, make other connections required for the correct type of system / device.
Remarks: consistent with requirements and recommendation of the producer.
6. Start the system (switch on ~230V), adjust or configure: according to procedure of the producer's
system.
3. Parametry techniczne / Technical data.
PARAMETRY
TECHNICZNE
Napięcie zasilania
Napięcie wyjściowe
U1/U2
Prąd wyjściowy nominalny
I1/I2
Zabezpieczenie przeciwzwarciowe i
przeciążeniowe
Złącza podłączeniowe
Obudowa: IP
Temperatura pracy /
Klasa cieplna
Wilgotność względna RH – max.
Wymiary (szer x wys x głeb)
TRP 20/U1/U2÷ TRP 40/U1/U2
Wymiary (szer x wys x głeb)
TRP 50/U1/U2÷ TRP 80/U1/U2
Waga netto
TRP 20/U1/U2÷ TRP 40/U1/U2
Waga brutto
TRP 20/U1/U2÷ TRP 40/U1/U2
Waga netto
TRP 50/U1/U2÷ TRP 80/U1/U2
Waga brutto
TRP 50/U1/U2÷ TRP 80/U1/U2
Tab 1.
Prior to entering installation it is necessary to make sure if the voltage
in the 230 V/AC circuit is disconnected.
Power supply voltage
Power supply voltage
Nominal output current
Short circuit and overload protection
Operating temperature /
Relative humidity RH –max.
Dimensions (W x H x D )
TRP 20/U1/U2÷ TRP 40/U1/U2
Dimensions (W x H x D )
TRP 50/U1/U2÷ TRP 80/U1/U2
TRP 20/U1/U2÷ TRP 40/U1/U2
TRP 20/U1/U2÷ TRP 40/U1/U2
TRP 50/U1/U2÷ TRP 80/U1/U2
TRP 50/U1/U2÷ TRP 80/U1/U2
voltage disconnected.
TECHNICAL
DATA
U1/U2
I1/I2
Terminal block
Casing: IP
Heat class
Net Weight
Gross Weight
Net Weight
Gross Weight
3
230V/AC, 50Hz
(-15%÷+10%)
Tab. 2
Tab. 2
Bezpiecznik / Fuse
Tab. 2
2,5mm2
IP 20
-10ºC÷40ºC
Ta 40B
90 [%]
80 x 103 x 76 [mm,+/-2]
95x 128 x 88 [mm,+/-2]
0,60/0,75/1,05 [kg, +/-10g]
0,65/0,80/1,10 [kg, +/-10g]
1,60/2,10/ [kg, +/-10g]
1,65/2,15/ [kg, +/-10g]
