AWZ 05122
v.1.1
AWZ 12V/2A/5x0,5A Linear power supply unit for CCTV
EN
Edition: 2 from the August 22, 2011
Supercedes edition: 1 from the 2nd February 2011

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AWZ 05122 and is the answer not in the manual?

Questions and answers

Summary of Contents for Pulsar AWZ 05122

  • Page 1 AWZ 05122 v.1.1 AWZ 12V/2A/5x0,5A Linear power supply unit for CCTV Edition: 2 from the August 22, 2011 Supercedes edition: 1 from the 2nd February 2011...
  • Page 2 Features of the power supply unit: • • five outputs protected independently by fuses Safety equipment: • total output current: 2A SCP short-circuit protection • output voltage adjustment 11÷15V OLP overload protection • OHP overheat protection LED optical signalisation OVP overvoltage protection Surge protection Against sabotage CONTENTS:...
  • Page 3 .2. Block diagram (fig.1). Fig.1. Block diagram of the power-supply unit. . Description of elements and power supply connectors (tab.1, tab.2, fig.2). Table 1. Element no Description [Fig. 2] L1, L2, L 3, L4, L5 optical signaling of outputs status ~AC~ AC supply signaling (only PCB) F1, F2, F3, F4, F5 fuses in the output circuit (DC) P1 voltage adjustment, output voltage adjustment...
  • Page 4 Fig.2. The view of the power-supply unit.
  • Page 5 1.4. Technical parameters: - electrical parameters (tab.3) - mechanical parameters (tab.4) - operation safety (tab.5) - operation parameters (tab.6) lectrical parameters (tab. 3). Supply voltage 230V AC (-15%/+10%) Supply frequency 50Hz (47÷53Hz) PSU power P 24W max. Current consumption 0.29A/230V Output voltage 12,0V DC nom.
  • Page 6 Installation 2.1 Requirements. The buffer power-supply shall be mounted by the qualified installer having appropriate (required and necessary for a given country) permissions and qualifications for connecting (operating) 230V AC installations and low-voltage installations. The device shall be mounted in closed rooms, according to the environment class II, of the normal air humidity (RH=90% max.
  • Page 7 Fig.3. The view of LED panel. Service and operation 4.1 Procedure in case of short-circuit (activation of SCP) of the power supply output. The O1÷ O5 outputs have short-circuit protection through application of fuses (fuse-elements) or PTC fuses. If a failure occurs, the fuse shall be replaced (the same as the original). It is acceptable to change values of fuses to other than original, if not all outputs of power supply are used and Pmax is not exceeded.
  • Page 8 EU. GENERAL WARRANTY CONDITIONS 1. Pulsar K. Bogusz Sp.j. (manufacturer) grants a two-year quality warranty for the equipment, starting from the date of purchase placed on the purchase order. 2. Should such purchase order be missing when the claim is submitted, the three-year guarantee period is counted from the date of the manufacturing of the device.
