Summary of Contents for Thundercomm TurboX M12M
- Page 1 Thundercomm TurboX M12M Development Kit Quick Start Guide Rev. V1.0 tc-C3-2110...
-
Page 2: Package List
Package List M12M Main IO Board M12M Main IO Board Cellular/GPS Antenna (x 2) (Top View) (Bottom View)` Copyright© 2023 Thundercomm Technology Co., Ltd. All rights reserved. -
Page 3: Interface List
2. SIM card slot 2 5. Power LED 3. SIM card slot 1 6. Auxiliary/GPS antenna connector 4. M.2 connector 7. M12M SOM 5. USB Type-C connector 8. Main antenna connector 6. Power switch Copyright© 2023 Thundercomm Technology Co., Ltd. All rights reserved. -
Page 4: Let's Get Started
3. Insert M12M SOM Module to M.2 connector (connector 3). 4. Connect the board to PC via the USB Type-C connector (connector 4) with a USB Type-C cable to power on the board. Copyright© 2023 Thundercomm Technology Co., Ltd. All rights reserved. - Page 5 The products described in this document are not intended for use in implantation or other life support applications failure to claim or delay in claiming such rights shall not be deemed to be a waiver of such rights by Thundercomm.
