6 Installing and Using the 4-Port PoweredUSB Hub
Connections

2.3.3 Jumpers

CyberData Corporation
Figure 2-4. Host Connector with Strain Relief
Jumpers 3 and 4
Jumpers 5 and 6
Jumper Positions
C
A
A
B
Jumper Table
Com Port A, Pin 1 JP3
Com Port A, Pin 8 JP4
Com Port B, Pin 1 JP5
Com Port B, Pin 8 JP6
930105A
Figure 2-5. Jumpers
Jumpers 1 and 2
C
A
B
A B C
12V 5V CD
12V 5V RI
12V 5V CD
12V 5V RI
C
B
Operations Guide
