LEHMANN GIRO RFID MIFARE Operating Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
GB
www.lehmann-locks.com
GIRO RFID MIFARE
Operating Instructions
Content
Page
General Description ................................................................................................................. 2
Functional Description / Overview of transponder cards ........................................................4
System components and package contents ............................................................................5
Dimensions .............................................................................................................................. 7
Change direction of rotating / Mounting on wood ..................................................................8
Mounting GIRO with the status indicator on wood / on metal ..............................................10
Emergency opening with service key / Getting started and changing batteries /
Tips for the following programming steps .............................................................................11
Closing and Opening .............................................................................................................. 13
Resetting to Factory Setting ...................................................................................................17
Activation and Deactivation of Automatic Locking ................................................................18
Reordering Master Cards / Firmware Update ........................................................................19
Disposal / Trouble Shouting ...................................................................................................20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GIRO RFID MIFARE and is the answer not in the manual?

Questions and answers

Related Manuals for LEHMANN GIRO RFID MIFARE

Summary of Contents for LEHMANN GIRO RFID MIFARE

  • Page 1: Table Of Contents

    GIRO RFID MIFARE Operating Instructions Content Page General Description ......................... 2 Technical Specifications / Safety Precautions / Care and Maintenance / Factory Settings ..3 Functional Description / Overview of transponder cards ............4 System components and package contents ................5 Dimensions ..........................7 Change direction of rotating / Mounting on wood ..............8...

  • Page 2: General Description

    GENERAL DESCRIPTION The GIRO RFID MIFARE lock is a battery-operated electronic furniture lock based on RFID technology, which is inten- ded for the inside of buildings. These operating instructions provide you with information on how to operate the locking system without errors. Keep the operating instructions in an easily accessible place. Improper use can destroy the locking system and lead to the loss of any warranty claims.

  • Page 3: Technical Specifications / Safety Precautions / Care And Maintenance / Factory Settings

    „Assigned use“ mode. MIFARE® Classic transponders cannot be used with the LMS. Support of NFC-enabled Android smartphones incl. LEHMANN Transponder App when configured by master card or LEHMANN Management Software LMS 2.x. Firmware vers. 2.x is required in the lock. Energy supply...

  • Page 4: Functional Description / Overview Of Transponder Cards

    FUNCTIONAL DESCRIPTION With the GIRO RFID MIFARE lock, you can conveniently lock and unlock your furniture. Non-contact RFID technology based on 13.56 MHz is used as the “key“. Two operating modes are available: Operating mode Description Assigned use There is a fixed assignment between the transponder cards and the locks. The user cards are programmed or deactivated at the lock by means of a master card.

  • Page 5: System Components And Package Contents

    • The comprehensive security concept, which was specially designed for this locking system in conjunction with the user cards of LEHMANN Vertriebsgesellschaft mbH & Co. KG, may be affected by the use of user cards of a third- party provider.
  • Page 6    Components: 7. Bolt (e.g. type 040) 1. Lock GIRO RFID MIFARE 8. Screw TX20n 2. Fixing element 1619 3. Screws 3 x 15 for fixing element 9. Striker plate 3011 with screws 3 x 15 10. Battery (CR123A) 4.

  • Page 7: Dimensions

    DIMENSIONS Lock Giro RFID MIFARE 20,5 32,5 SW16 open closed geöffnet verschlossen Bolt 031 Bolt 039 Bolt 040 Striker plate 3011 Status indicator (optional) Fixing element 1619 All dimensions in mm.

  • Page 8: Change Direction Of Rotating / Mounting On Wood

    CHANGE DIRECTION OF ROTATING The lock can be used for right hand doors and left hand doors.. For right hand doors: For left hand doors: MOUNTING ON WOOD ATTENTION: Install the lock only when it is unlocked. Carry out all programming processes and functional checks with the cabinet door open.

  • Page 9: Mounting On Metal Surfaces / Assembly Instructions For The Status Indicator

    MOUNTING ON METAL SURFACES Dimensions refer to bolt type 031. ASSEMBLY INSTRUCTIONS FOR THE STATUS INDICATOR unlocked locked All dimensions in mm.

  • Page 10: Mounting Giro With The Status Indicator On Wood / On Metal

    MOUNTING GIRO WITH STATUS INDICATOR ON WOOD When mounting the lock with the status indicator on wood, the fixing element 1619 is required. Dimensions refer to bolt type 040. MOUNTING GIRO WITH STATUS INDICATOR ON METAL SURFACES Dimensions refer to bolt type 039. All dimensions in mm.

  • Page 11: Tips For The Following Programming Steps

    EMERGENCY OPENING WITH SERVICE KEY 1. Turn the key 45° 2. Turn the turn to the left knob by 45° 3. Turn the key 45° to 4. Lock is open the right GETTING STARTED AND CHANGING BATTERIES Inserting the battery Battery is inserted correctly in the battery compartment IMPORTANT:...

  • Page 12: Using The Installation Card / Programming The Master Card / Prog. The User Cards

    USING THE INSTALLATION CARD (optinal) During installation, one or more installation cards can be used. The installation cards are ready for immediate use and do not have to be programmed. With the installation cards, the basic functions (opening and closing) can be carried out on the lock.

  • Page 13: Closing And Opening

    Programming user cards Hold the master card in front of the lock. Hold the user card in front of the lock. The card is accepted and programmed. This process can be repeated to program multiple user cards. Card is not accepted. Hold the master card in front of the lock.

  • Page 14: Unauthorised Transponder Cards / Facility Manager Function / Emergency Opening

    UNAUTHORISED TRANSPONDER CARDS Rejection of an unauthorised user card Unauthorised user card is held in front of the lock. The card is rejected. FACILITY MANAGER FUNCTION In the event that an authorised person only briefly wants to check whether for example a cabinet is actually occupied, the lock can be opened with the master card.

  • Page 15: Deleting Individual Transponder Cards / Deleting All Transponder Cards

    DELETING INDIVIDUAL TRANSPONDER CARDS (only for “assigned use” mode) Insofar as further user cards were programmed on the lock, these can continue to be used on this lock after an individual user card has been deleted. For the deleting process, the lock must be open. To do this, first carry out an emergency opening with the master card if necessary (see Emergency opening, P.

  • Page 16: Changing The Operating Mode / Deactivating And Activating Acoustic Signals

    To do this, the master card and the programming card “P1: Mode“ are required. The programming card set must be bought separately from LEHMANN Vertriebsgesellschaft mbH & Co. KG. The cards are for universal use. Changing the operating mode Hold the master card in front of the lock.

  • Page 17: Resetting To Factory Setting

    The reset function can be used with the master card and programming card “P3: Reset“. For this, the lock must be open. The programming card set must be bought separately from LEHMANN Vertriebsgesellschaft mbH & Co. KG. The cards are for universal use.

  • Page 18: Activation And Deactivation Of Automatic Locking

    “assigned use“ and in an open position. If the operating mode changes, this function is automatically deactivated. The programming card must be purchased separately from LEHMANN Vertriebsgesellschaft mbH & Co. KG. The card can be used universally.

  • Page 19: Activation And Deactivation Of Unlimited Shared Use / Battery Warning / Reordering Master Cards / Firmware Update

    For this you obtained a service key together with the master cards. Please keep the service key carefully and securely. The service key makes it possible to reorder the master card specified there. To reorder these cards, please contact LEHMANN Vertriebsgesellschaft mbH & Co. KG at the following email address: sales@lehmann-locks.com In your email, please give us your contact data and the service key.

  • Page 20: Disposal / Trouble Shouting

    Battery warning The battery must be replaced without delay. Phase 2 LEHMANN Vertriebsgesellschaft mbH & Co. KG Postfach 26 20 • D-32383 Minden Fon +49 571 / 50 599-0 • Fax +49 571 / 50 599-822 info@lehmann-locks.com • www.lehmann-locks.com...
