CAPTOS MIFARE
Operating Instructions
Content
Safty Precautions ..................................................................................................................... 3
Care & Maintenance / Factory Settings / Functional Description /
Overview of transponder cards / ............................................................................................4
Additional functions with the Captos iCharge ..........................................................................5
Dimensions............................................................................................................................... 7
General assembly instructions / Mounting on non-metal surfaces .........................................9
Cable management recommendations ..................................................................................12
Configuration and operation ..................................................................................................14
Instructions for operation and configuration .........................................................................15
Programming the User Cards / Closing and opening .............................................................17
Deleting Individual Transponder Cards ..................................................................................19
Deleting All Transponder Cards / Changing the operating mode ...........................................20
Deactivating and activating acoustic signals ..........................................................................21
Deactivating and activating the Status-LED ............................................................................23
Disposal .................................................................................................................................. 24
CAPTOS MIFARE /
CAPTOS iCharge MIFARE
CAPTOS iCharge MIFARE
GB
Page

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CAPTOS MIFARE and is the answer not in the manual?

Questions and answers

Related Manuals for LEHMANN CAPTOS MIFARE

Summary of Contents for LEHMANN CAPTOS MIFARE

  • Page 1: Table Of Contents

    CAPTOS iCharge MIFARE CAPTOS MIFARE CAPTOS MIFARE / CAPTOS iCharge MIFARE Operating Instructions Content Page General Description / Supplementary documents / Technical Specifications ......2 Safty Precautions ........................3 Care & Maintenance / Factory Settings / Functional Description / Overview of transponder cards / ....................4 Additional functions with the Captos iCharge ................5...

  • Page 2: General Description / Supplementary Documents / Technical Specifications

    Captos and Captos iCharge. Captos iCharge has the same functions as the Captos plus a USB charging function for smartphones and tablets as well as RGB backlighting that can be individually adjusted in color in the LEHMANN Management Software LMS. Emergency equipment, vital medicines and similar items must not be locked with these locks, as access to these items cannot be guaranteed in the event of a malfunction.

  • Page 3: Safty Precautions

    RS485 via custom 4-wire cable Connector RJ12 Up to 30mm with LEHMANN user cards (MIFARE® DESFire® EV1). Other transponders may have a shorter reading distance and must be checked in advance. The material of the Reading distance furniture can influence the reading distance. A test on the furniture regarding the reading distance is therefore recommended.

  • Page 4: Overview Of Transponder Cards

    (opening and closing). This card is for universal use. Prior programming of (only for assembly a master card is not necessary. After programming the lock with a master card or with the LEHMANN and testing Management Software LMS, the lock is disabled for the installation card.

  • Page 5: Additional Functions With The Captos Icharge

    This card has no electronic function! You can either use user cards from LEHMANN or a third-party provider based on ISO 14443A as transponders / user cards. Please note the possible restrictions on user cards from third-party providers: •...

  • Page 6: Power Supply / Components Of The Locking System & Package Content

    POWER SUPPLY The lock is powered by a controller. To do this, the lock must be connected to a controller by using a connecting cable. Further information on the controllers and on commissioning the controllers can be found in the operating instruc- tions „Primary Controller / Secondary Controller“.

  • Page 7: Dimensions

    DIMENSIONS Lock Captos 16,5 Lock Captos iCharge (with USB charging function and backlinghting) 16,5 Locking Pin Type C Screw hole Opening for optional lightpoint* Opening for optional lightpoint* Screw hole installing only one lightpoint is recommended All information in mm...
  • Page 8 Ejector pin A2 (optional) (38) 14,7 118,6 (38) (38) 14,7 Lightpoint (optional) 118,6 118,6 118,6 Lightpoint O16.1 for wood with Lightpoint O10.1 for wood with material thickness of 16-21 mm material thickness of 10-15 mm 2.500 Connecting cable lock - controller 2.500 Further lengths on request...

  • Page 9: General Assembly Instructions / Mounting On Non-Metal Surfaces

    GENERAL ASSEMBLY INSTRUCTIONS IMPORTANT: Only install the locking system when it is unlocked. Hand-tighten all screws. The use of the ejector pin in connection with spring-loaded hinges must be checked on a project-specific basis. Maximum door thickness for non-metallic doors: 19 mm The maximum door thickness for non-metallic doors depends, among other things, on the reading range between the lock and the transponder.
  • Page 10 • Screw the lock onto the wall unit. Hand-tighten all screws. The lock must lie flat on the wall unit. The connec- tion cable must not be squeezed. • Pre-drill the two mounting holes for the locking pin on the inside of the door as shown in the drawing (see figure: mounting position on non-metallic surfaces).
  • Page 11 Figure: Plug the connecting cable into the lock 1. Insert the connector of the 2. For later assembly or disassembly purposes, stow the connec- connecting cable into the tion cable approx. 10-15cm in loops in the lock. Lead the cable socket in the lock.

  • Page 12: Cable Management Recommendations

    Installation instructions for the optional lightpoint O10.1 or O16.1 Note that the lightpoint can be mounted optionally. Without a lightpoint, only acoustic signals are available. The lock has two LEDs aligned symmetrically on the front of the lock. Only one lightpoint in the door is recommended for each lock.
  • Page 13 b) Cable routing on the inside of the body made of wood or HPL with grooves Side wall (inside) with Rear panel of locker with Connect the cable to the lock, lay groove 8x3mm. 12mm hole. it in the groove and feed it through the hole on the back.

  • Page 14: Configuration And Operation

    CONFIGURATION AND OPERATION The locking system can be configured with master and programming cards or with the LEHMANN management soft- ware LMS. For full use of the locking system, networking via the customer‘s LAN with the LMS is recommended.

  • Page 15: Instructions For Operation And Configuration

    INSTRUCTIONS FOR OPERATION AND CONFIGURATION To read a transponder, the locking pin on the inside of the door must be in the lock. To do this, close the door. When using an ejector pin, press the door into the lock with one hand while programming.

  • Page 16: Commissioning / Using The Installation Card / Programming The Master Card

    COMMISSIONING Power supply is established Power supply is established USING THE INSTALLATION CARD During installation, one or more installation cards can be used. The installation cards are ready for immediate use and do not have to be programmed. With the installation cards, the basic functions (opening and closing) can be carried out on the lock.

  • Page 17: Programming The User Cards / Closing And Opening

    The locking system is in „assigned use“ mode after the master card has been programmed. If you would like to use the lock in “shared use“ mode, the next thing to do is to change the operating mode. To do this, please follow the instructions on page 20 and then continue with the section “Closing and Opening“...

  • Page 18: Unauthorised Transponders / Facility Manager Function / Emergency Opening

    Opening Hold the user card in front of the lock. UNAUTHORISED TRANSPONDERS Rejection of an unauthorised user card Unauthorised user card is held in front of the lock. The card is rejected. FACILITY MANAGER FUNCTION In the event that an authorised person only briefly wants to check whether for example a locker is occupied, the lock can be opened with the master card.

  • Page 19: Deleting Individual Transponder Cards

    Emergency Opening Hold the master card in front of the lock. Hold the master card in front of the lock. DELETING INDIVIDUAL TRANSPONDER CARDS (only for “assigned use” mode) If further user cards were programmed on the lock, these can continue to be used on this lock after an individual user card has been deleted.

  • Page 20: Deleting All Transponder Cards / Changing The Operating Mode

    The lock has two modes: “assigned use“ and “shared use“. When the lock is open, you have the option of changing the mode. To do this, the master card and the programming card No. 1 (P1: Mode) are required. The programming card set must be bought separately from LEHMANN Vertriebsgesellschaft mbH & Co. KG. The cards are for universal use.

  • Page 21: Deactivating And Activating Acoustic Signals

    Please note that the acoustic signals for the battery warning and for changing the operating mode cannot be deactivated. The programming card set must be bought separately from LEHMANN Vertriebsgesellschaft mbH & Co. KG. The cards are for universal use.

  • Page 22: Resetting To Factory Settings / Activation And Deactivation Of Auto Locking

    The reset function can be used with the help of the master card and programming card No. 3 (P3: Reset). For this, the lock must be open. The programming card set must be bought separately from LEHMANN Vertriebsgesellschaft mbH & Co. KG. The cards are for universal use.

  • Page 23: Deactivating And Activating The Status-Led

    Activate or deactivate the feature automatic locking Hold the master card in front of the lock. Auto locking is activated Hold the programming card “P4: Auto Locking” in front of the lock. The function “auto locking” is activated. Auto locking is deactivated Hold the programming card “P4: Auto Locking”...

  • Page 24: Disposal

    DISPOSAL Dispose of the locking system in accordance with local regulations and guidelines. LEHMANN Vertriebsgesellschaft mbH & Co. KG Uphauser Weg 82 • D-32429 Minden Fon +49 571 / 50 599-0 • Fax +49 571 / 50 599-822 info@lehmann-locks.com •...
