Omron E6F-C Datasheet

Incremental Rotary Encoder 60 mm dia.

E6F-C
The Strongest Shaft for
Tough Jobs
• The strongest shaft of any OMRON Incremental En-
coder (120 N in radial direction and 50 N in thrust di-
rection).
• Water- and oil-proof structure (IP65f)
• Output short-circuit protection circuit to reduce risks
from incorrect wiring.
• Complementary output model can be used with ex-
tension cable
• Shock resistance strengthened by metal disk. (600
P/R max.)
Patent

Ordering Information

Sensors
Supply voltage
12 to 24VDC

Accessories (Order Separately)

Item Model
E69-C10B
Coupling
E69-C610B
E69-C10M
Mounting Bracket E69-2

Dimensions (Unit: mm)

Sensors
E6F-CWZ5G
Four, M3 holes Depth: 6
48 dia.
90˚
90˚
60 dia.
54 dia.
90˚
90˚
N o t e :
2 - m - l o n g , o i l - r e s i s t i v e P V C c a b l e ,
17
5 - d i a . ( c o n d u c t o r c r o s s - s e c t i o n : 0 . 2 m m
i n s u l a t o r : 1 . 0 d i a . ) f i v e c o n d u c t o r s a n d
s h i e l d ( e i g h t c o n d u c t o r f o r l i n e d r i v e r u s e )
E6F-C
Output form
Complimentary output
---
Different end diameter
Metal construction
Three brackets in a set; included with the Encoder.
(85)
60
20 5
3
15 3
1
0
10 dia.
-0.015
0
40 dia.
- 0.025
14 max.
(see note)
42.5
2
,
2,000
Resolution (pulse/rotation)
100, 200, 360, 500, 600
1000
Remarks
Accessories (Order Separately)
Servo Mounting Bracket
E69-2
+2
10
0
100 ±10
Model
E6F-CWZ5G
2
5.5 dia. Hole
(18) 16
9
+0.1
3.1
8
0
Two-C1
16
(5.1)
E-9
