Absolute 60-mm-dia. Rotary Encoder
E6F-A
High Accuracy and Durability
for Automatic Equipment
• Stronger shaft and greater durability (120 N in the ra-
dial direction and 50 N in the thrust direction) than
previous E6F Encoders.
• Water- and oil-proof structure (IP65f) for a greater de-
gree of protection against water, oil, and other sub-
stances.
• Wider range of resolutions for even more applications
(series includes models with resolutions up to 1,024).
• Faster response for high-speed control applications
(grey code: 20 kHz).
Ordering Information
■ Rotary Encoders
Supply voltage Output configuration
5 to 12 VDC NPN open collector
12 to 24 VDC
PNP open collector
NPN open collector
PNP open collector
Note 1. When ordering, specify the resolution together with the model number (e.g., F6F-AG5C 256).
2. The E6F-AB3C-C connects to the H8PR-8, H8PR-16, or H8PR-24 Rotary Positioner.
3. The E6F-AG5C-C connects to the H8PS-8A or H8PS-8AF Cam Positioner.
■ Accessories (Order Separately)
Name
Coupling E69-C10B
E69-C610B
E69-C10M
Servo Mounting Brackets E69-2
Extension Cable E69-DF5
Output code
BCD
Grey binary
Model
Included with the E6F-AB3C.
Different end diameter
Metal construction
Three brackets in a set; included with the Encoder.
5 m
(10-, 15-, 20-, and 98-m cables are also available.)
Resolution (P/R)
360 Prewired
Connector
Prewired
Connector
Prewired
256 Connector
256, 360, 720, or 1,024 Prewired
Remarks
Connection Model
E6F-AB3C
E6F-AB3C-C
E6F-AB5C
E6F-AB5C-C
E6F-AB5B
E6F-AG5C-C
E6F-AG5C
E6F-AG5B
.
