Summary of Contents for TW Audio QBM6
- Page 1 Assembly QBM6 Instructions...
- Page 2 If you lend your product to another party, inform that party of the safety-related operating pro- cedures and hand over this assembly guide. If you require additional copies of this manual, you can obtain them free of charge from TW AUDiO or download them from www.twaudio.de Instructions in this user manual...
- Page 3 Assembly Instructions QBM6 Notes on the products Before using the device, carefully read the assembly instructions and keep it with the QBM6 swi- Read manual vel bracket. before use! General information Assembly instructions: OM-QBM6 Version 2.1 en, 08/2023 © by TWAMBO 2023; all rights reserved.
-
Page 4: Table Of Contents
Needed tools for setup ..................10 Wind load ......................10 Assembly QBM6 to loudspeaker ................11 Assembly QBM6 swivel bracket to trusses, ceiling or wall ........12 Assembly QBM6 swivel bracket on tripod .............. 13 5. Transport and storage ....................14 6. -
Page 5: Safety | Intended Use
Damage caused by improper use is not covered by TWAMBO. Before every operation, check the scope of delivery of the QBM6 swivel bracket for its com- pleteness and ensure that all parts are in perfect condition. The scope of delivery includes specified components. Only use the recommended and cer- WARNING tified components. - Page 6 Assembly Instructions QBM6 The payload of the QBM6 swivel bracket is designed of one M6 loudspeaker. Do not exceed this payload. WARNING Before mounting the QBM6 swivel bracket check that e.g. ceilings, trussus and tripods are capable to carrying the payload of the components.
-
Page 7: Overview
Assembly Instructions QBM6 2. Overview Components Figure 2.1 - Overview Hexagon screw M10 x 20................2 pieces Washer (metal)....................2 pieces Rubber break washer ..................2 pieces Swivel bracket QBM6 ..................1 piece... -
Page 8: Technical Data
Assembly Instructions QBM6 3. Technical data Data sheet Maximum load capacity 1x M6 Dimensions (h x w x d) 148 x 372 x 40mm [5.83 x 14.65 x 1,58 in] Weight 1,5 kg [3.3 lbs] Surface Powder-coated... -
Page 9: Commissioning
4. Commissioning Setup The QBM6 swivel bracket is designed for the hanging and stacking operation. TW AUDiO provides a wide range of accessories to securely attach the swivel bracket. Please note that setting up the system structures always requires two persons! -
Page 10: Needed Tools For Setup
Assembly Instructions QBM6 Needed tools for setup Have the following tools ready for each setup: • Cutter knife • Torque wrench • Bit insert for torque wrench: TX30 • Open-end wrench SW17 Wind load Before setting up the system outdoors, consider unexpected wind conditions at the opera-... -
Page 11: Assembly Qbm6 To Loudspeaker
Mount positions 1 to 3 (see figure 2.1) on both sides as shown in figure 4.4. Note that at pos.4 (see figure 2.1) one of the side holes is used. NOTE Pos.4 Pos.3 Pos.2 Pos.1 Figure 4.5 - Assembly QBM6 to M6 loudspeaker... -
Page 12: Assembly Qbm6 Swivel Bracket To Trusses, Ceiling Or Wall
Assembly QBM6 swivel bracket to trusses, ceiling or wall Attach the DHST Doughty Halfcoupler Slimline to the ø12.2mm hole located on the crossbar of the QBM6 swivel bracket when using the QBM6 swivel bracket on trusses. Make sure that the connections are set firmly and correctly! -
Page 13: Assembly Qbm6 Swivel Bracket On Tripod
Assembly Instructions QBM6 Assembly QBM6 swivel bracket on tripod Mount the M6 loudspeaker with QBM6 swivel bracket and the HSF pole mount flange on the tripod. Make sure that you use suitable fastening material and that the connections are set... -
Page 14: Transport And Storage
For this reason, the loudspeakers should be transported and stored in a safe, careful, dry and largely dust-free manner. The following accessory parts for the swivel bracket are available from TW AUDiO: • Hexagon screw M10 x 20 •... -
Page 15: Ce Conformity Declaration
Assembly Instructions QBM6 6. CE Conformity Declaration Copy and translation of the original CE Conformity Declaration: We hereby declare that the below-referenced components by virtue of their design and con- struction, and in the configuration placed on the market by us, satisfy the safety and health requirements of the applicable EC directives. - Page 16 Assembly Instructions QBM6 TWAMBO GmbH Karl-Hofer-Str. 42 14163 Berlin Germany Phone: + 49 (0) 71 41-48 89 89 0 Fax: + 49 (0) 71 41-48 89 89 99 E-Mail: info@twaudio.de WWW: www.twaudio.de...
