Summary of Contents for TW Audio BCT24
- Page 1 Assembly BCT24 Instructions...
- Page 2 If you lend your product to another party, inform that party of the safety-related operating pro- cedures and hand over this assembly guide. If you require additional copies of this manual, you can obtain them free of charge from TW AUDiO or download them from www.twaudio.de Instructions in this user manual...
- Page 3 Assembly Instructions BCT24 Notes on the products Before using the device, carefully read the assembly instructions and keep it with the Read manual BCT24 rigging adapter . before use! General information Assembly instructions: OM-BCT24 Version 2.0 en, 08/2022 © by TWAMBO 2022; all rights reserved.
-
Page 4: Table Of Contents
Setup ........................9 Usage ........................9 Wind load ........................ 9 Mounting BCT24 rigging adapter at CBT24 cradle bar for flying ......10 System setup BCT24 with CBT24, BBT24 and T24(N) loudspeaker ...... 10 5. Transport and storage ....................12 6. CE Conformity Declaration .................... 13... -
Page 5: Safety | Intended Use
Damage caused by improper use is not covered by TWAMBO. Before every operation, check the scope of delivery of the BCT24 rigging adapter for its com- pleteness and ensure that all parts are in perfect condition. The scope of delivery includes specified components. Only use the recommended and cer- WARNING tified components. - Page 6 Multiple persons may be required depending on the situation. NOTE The payload of the BCT24 rigging adapter is designed of not more than six T24(N) loudspe- aker. The following additional components are required for this: CBT24 cradle bar for flying, BBT24 bracket and BLT24 Boxlink connecting cables on both sides of the T24(N) loudspea- ker.
-
Page 7: Overview
Assembly Instructions BCT24 2. Overview Components Figure 2.1 - Overview Rigging adapter ....................1 piece Hexagon screw M12 x 30................2 pieces Hexagon nut with clamping part M12 .............. 2 pieces... -
Page 8: Technical Data
Assembly Instructions BCT24 3. Technical data Data sheet Maximum load capacity: in combination with: 1x T24(N) 1x CBT24 cradle bar for flying and 1x BBT24 bracket Maximum load capacity: in combination with: 1x CBT24 cradle bar for flying, 6x T24(N) -
Page 9: Commissioning
4. Commissioning Setup The BCT24 rigging adapter is designed for hanging operation. TW AUDiO provides a wide range of accessories to securely attach the rigging adapter . Please note that setting up the BCT24 rigging adapter always requires two persons! -
Page 10: Mounting Bct24 Rigging Adapter At Cbt24 Cradle Bar For Flying
Assembly Instructions BCT24 Mounting BCT24 rigging adapter at CBT24 cradle bar for flying Mount the BCT24 rigging adapter to the CBT24 cradle bar for flying with both screws and nuts as shown in figure 4.4. WARNING Before mounting the CBT24 cradle bar for flying, observe its assembly and safety instruc-... - Page 11 T24 (N) BBT24 Figure 4.5 - Mounting BCT24 rigging adapter with all assemblies General safety instructions for setting up this rigging variant: Use shackles that are designed according to the payload for each system setup. WARNING For the secondary safety component, the respective national electrotechnical regulations apply.
-
Page 12: Transport And Storage
This is why the product should be transported in a safe, careful, dry and largely dust-free manner. The following accessory parts for the rigging adapter are available from TW AUDiO: • Hexagon screw M12 x 30 • Hexagon nut M12... -
Page 13: Ce Conformity Declaration
Assembly Instructions BCT24 6. CE Conformity Declaration Copy and translation of the original CE Conformity Declaration: We hereby declare that the below-referenced components by virtue of their design and con- struction, and in the configuration placed on the market by us, satisfy the safety and health requirements of the applicable EC directives. - Page 14 Assembly Instructions BCT24 TWAMBO GmbH Karl-Hofer-Str. 42 14163 Berlin Germany Phone: + 49 (0) 71 41-48 89 89 0 Fax: + 49 (0) 71 41-48 89 89 99 E-Mail: info@twaudio.de WWW: www.twaudio.de...
