Summary of Contents for TW Audio QBM10i
- Page 1 Assembly QBM10i Instructions...
- Page 2 If you lend your product to another party, inform that party of the safety-related operating pro- cedures and hand over this assembly guide. If you require additional copies of this manual, you can obtain them free of charge from TW AUDiO or download them from www.twaudio.de Instructions in this user manual...
- Page 3 Assembly Instructions QBM10i Notes on the products Before using the device, carefully read the assembly instructions and keep it with the Read manual QBM10i swivel bracket. before use! General information Assembly instructions: OM-QBM10i Version 1.0 en, 04/2024 © by TWAMBO 2024; all rights reserved.
-
Page 4: Table Of Contents
Needed tools for setup ..................10 Wind load ......................10 Assembly QBM10i to loudspeaker ................. 11 Assembly QBM10i swivel bracket to ceiling or wall ..........11 5. Transport and storage ....................12 6. CE Conformity Declaration .................... 13 7. Disposal ........................13... -
Page 5: Safety | Intended Use
Damage caused by improper use is not covered by TWAMBO. Before every operation, check the scope of delivery of the QBM10i swivel bracket for its completeness and ensure that all parts are in perfect condition. The scope of delivery includes specified components. Only use the recommended and cer- WARNING tified components. - Page 6 Assembly Instructions QBM10i The payload of the QBM10i swivel bracket is designed of one M10i loudspeaker. Do not exceed this payload. WARNING Before mounting the QBM10i swivel bracket check that e.g. ceilings, walls are capable to carrying the payload of the components.
-
Page 7: Overview
Assembly Instructions QBM10i 2. Overview Components Figure 2.1 - Overview Hexagon screw M10 x 30................2 pieces Washer (metal)....................2 pieces Rubber break washer ..................2 pieces Swivel bracket QBM10i ..................1 piece... -
Page 8: Technical Data
Assembly Instructions QBM10i 3. Technical data Data sheet Maximum load capacity 1x M10i Dimensions (h x w x d) 255 x 550 x 50 mm [10.04 x 21.65 x 1.97 in] Weight 2 kg [4.41 lbs] Surface Powder-coated... -
Page 9: Commissioning
Assembly Instructions QBM10i 4. Commissioning Setup The QBM10i swivel bracket is designed for hanging operation. TW AUDiO provides a wide range of accessories to securely attach the swivel bracket. Please note that setting up the system structures always requires two persons! -
Page 10: Needed Tools For Setup
Assembly Instructions QBM10i Needed tools for setup Have the following tools ready for each setup: • Cutter knife • Torque wrench • Bit inserts for torque wrench: TX30 and TX50 • Open-end wrench SW17 Wind load Before setting up the system outdoors, consider unexpected wind conditions at the opera-... -
Page 11: Assembly Qbm10I To Loudspeaker
Assembly QBM10i swivel bracket to ceiling or wall Attach the QBM10i swivel bracket to the ceiling or wall by using all three holes located on the crossbar. Make sure that you use suitable fastening material and that the connections are set... -
Page 12: Transport And Storage
For this reason, the loudspeakers should be transported and stored in a safe, careful, dry and largely dust-free manner. The following accessory parts for the swivel bracket are available from TW AUDiO: • Hexagon screw M10 x 30 •... -
Page 13: Ce Conformity Declaration
Assembly Instructions QBM10i 6. CE Conformity Declaration Copy and translation of the original CE Conformity Declaration: We hereby declare that the below-referenced components by virtue of their design and con- struction, and in the configuration placed on the market by us, satisfy the safety and health requirements of the applicable EC directives. - Page 14 Assembly Instructions QBM10i TWAMBO GmbH Karl-Hofer-Str. 42 14163 Berlin Germany Phone: + 49 (0) 71 41-48 89 89 0 Fax: + 49 (0) 71 41-48 89 89 99 E-Mail: info@twaudio.de WWW: www.twaudio.de...
