Creating Simple Function Block Data for
the Loop Controller
Paste the function block Isolated Ao 4-
point Terminal (DA041) for analog
output in the same way. Right-click in
the window on the right and select
Register - Field Terminal. Set the
Field Terminal to Ao 4-point (DA041).
4
5
This completes pasting the function
blocks.
5
5

Connecting Function Blocks

Connecting Function Blocks
Next, connect the function
blocks that were pasted.
First, click the Right Arrow
Y1 Terminal of the Ai 4-point (PTS51)
block.
Drag the mouse to the PV Terminal
of the Basic PID Block and double-click.
1-8
4-5. Register the Ao 4-point Terminal (DA041).
of the
5-1-1. Click the Right Arrow
of the Y Terminal.
5-1-2. Drag the mouse.
5-1-3. Double-click.
