PLC Network
PLC
Start-Up
Start-Up
Starting CX-Integrator
Click
Select a serial port,
then click [Connect]
DeviceNet NT Link
Start-Up Start-Up

PLC Network Start-Up

PLC Network Start-Up
Online Connection to PLC (Automatic Online Connection)
Online Connection to PLC (Automatic Online Connection)
1. From the [Start] menu, select [Programs] > [OMRON] > [CX-One] > [CX-Integrator] > [CX-
Integrator] to start CX-Integrator. (Or select [All Programs] > [OMRON] > [CX-One] > [CX-
Integrator] > [CX-Integrator])
CX-Integrator starts and automatically connects online.
Select a serial port.
When USB conversion cable (CS1W-CIF31)
is used for connection, specify the COM port
number of the USB port used.
Controller
CompoWay
Link
/F Start-Up
Start-Up
Saving Equipment
System Disass'y /
Config. Reass'y Verification
(Important)
(Important)
This operation is used for online
This operation is used for online
connection to any PLC hereinafter.
connection to any PLC hereinafter.
Unless described otherwise, use
Unless described otherwise, use
this operation to connect online.
this operation to connect online.
All communications Units and ports of
a connected PLC are automatically
displayed in the online connection
information window.
System Controller
Config. Link
Diagnosis
