Design; Starting Cx-Programmer - Omron CX-ONE - INTRODUCTION GUIDE Introduction Manual

Starting CX-

Design

Programmer

Starting CX-Programmer

Creating a New Project
Click .
Click and select
PLC model.
Setting
Creating Unit
CPU Bus
Configuration
Units/SIOU
Starting CX-Programmer
Starting CX-Programmer
From the [Start] menu, select [Programs] > [OMRON] > [CX-One] > [CX-Programmer] > [CX-
Programmer] to start CX-Programmer. (Or select [All Programs] > [OMRON] > [CX-One] >
[CX-Programmer] > [CX-Programmer])
Click this button to create a new CX-Programmer project.
Left-click
Select a PLC model from the following to use Function Blocks.
CS1G-H, CS1H-H, CJ1G-H, CJ1H-H, CJ1M
Checking I/O
Programming
Assignment
Dedicated Support Software for each Unit can be
started, succeeding communications settings from
CX-Programmer. You will not have to set up
communications using dedicated Support Software
if you set up communications here.
Click and select CPU type.
Saving
Offline Debug
a Project
Click [OK] and
determine CPU type.
