- Page 1 EN Installation / User Instructions / Warranty FR Instructions de montage / Mode d'emploi / Garantie ES Instrucciones de montaje / Manejo / Garantía Talis C 14111xx1 Talis C 14116xx1 Talis C 14120xx1...
-
Page 2: Technical Information
English Français Technical Information Données techniques Recommended water pressure 15 - 75 PSI Pression d’eau recommandée 15 - 75 PSI Max. water pressure 145 PSI Pression d’eau maximum 145 PSI Recommended hot water temp. 120° - 140° F* Température recommandée 120° - 140° F* Max. hot water temp 176°F* d'eau chaude Flow rate - lavatory 1.2 GPM Température maximum d'eau chaude 176°F* Flow rate - bidet 2.2 GPM Capacité nominale - lavabo 1.2 GPM Hole size in mounting surface 1⅜" Capacité nominale - bidet 2.2 GPM Max. depth of mounting surface 1⅝" Dimension du trou dans la surface 1⅜ po de montage Profondeur maximale de la surface 1⅝ po *Please know and follow all applicable local plumbing de montage codes when setting the temperature on the water heater. -
Page 3: Datos Tecnicos
Español Datos tecnicos Tools Required / Outiles Utiles / Herramientas Útiles Presión recomendada en servicio 15 - 75 PSI Presión en servicio max. 145 PSI Temperatura recomendada del 120º - 140º F* agua caliente Temperatura del agua caliente max. 176º F* Caudal máximo - lavabo 1.2 GPM Caudal máximo - bidé 2.2 GPM Tamaño del orificio en la superficie 1⅜" de montaje Profundidad máxima de la 1⅝" superficie de montaje *Debe conocer y cumplir todos los códigos locales aplicables para ajustar la temperatura del calentador de agua. This unit meets or exceeds the following: Consideraciones para la instalación • ASME A112.18.1 •... - Page 4 14111xx1 14120xx1 4" 2⅛" 2⅛" 1¼" 1¼" ⅜ ⅜ 14116xx1 88509xx0 2¼" 1¼" 1¼" O.D.
-
Page 5: Installation / Installation / Instalación
Installation / Installation / Instalación English Français Español Install the drain pull rod on the Installez la tirette. Instale el tirador. faucet. Placez le robinet et l’anneau Coloque el grifo y el aro de Position the faucet and sealing d’étanchéité sur la surface de sellado sobre la superficie de ring on the mounting surface. - Page 6 5.9 ft-lb 8 Nm 2.2 ft-lb 3 Nm English Français Español Tighten the tensioning screws. Serrez les vis de pression à l’aide Apriete los tornillos tensores con d’un tournevis. un destornillador. Connect the hoses to the stops. Connectez les tuyaux d’arrivée Conecte las mangueras de sumi- d’eau chaude et d’eau froide nistro de agua caliente y fría a Use two wrenches, aux les butées d’arrêt. los topes. as shown, to prevent Utilisez deux clés, tel qu’illustré.
- Page 7 > 2 min 22 mm 22 mm 1.47 ft-lb / 2 Nm English Français Español Remove the aerator. Retirez l’aérateur. Retire el aireador. Flush the faucet for at least two Rincez le robinet pendant au Lave el grifo durante al menos 2 minutes. moins 2 minutes. minutos. Replace the aerator. Installez l’aérateur. Instale el aireador. Do not overtighten the Ne serrez pas trop No apriete el aireador aerator, or damage...
- Page 8 Installation / Installation / Instalación shorter longer plus cort plus longs más corto más largo Petroleum-based plumbers putty Le mastic de pétrole-basé peut en- Masilla de petróleo-basó puede can damage the surface of some dommager la surface de quelque dañar la superficie de algún ba- sinks. Please consult the manu- baignoires. S'il vous plaît consulter ñeras. Consulte por favor al fab- facturer of the sink regarding compatible le fabricant du baignoire quant aux en- ricante del bañera con respecto a sella- sealants.
- Page 9 Set the High Temperature Limit Stop (optional) / Réglage de la butée limite d’eau chaude (en option) / Ajuste el tope de límite de alta temperatura (opcional) 4 mm 4 mm 97°F 100°F 109°F 122°F 131°F 140°F 4 mm 4 mm 4 mm 4 mm...
- Page 10 Replacement Parts / Pièces détachées / Repuestos 14191xx0 96338000 98863xx0 98864000 13912xx0 95140000 95973001 98865000 92036xx0 98866000 96321001 - 18" 96316001 - 35" 96657xx0 88509xx0 92879000 - chrome 92879820 - brushed nickel 92877920 - rubbed bronze 13961000 xx = finish / couleurs / acabados 00 = chrome 82 = brushed nickel 92 = rubbed bronze...
- Page 11 User Instructions / Instructions de service / Manejo fermé ouvert cerrar abierto cold chaud froid caliente frío Cleaning / Nettoyage / Limpieza 22 mm...
- Page 12 Cleaning Recommendation for Hansgrohe Products Modern bathroom faucets, kitchen faucets and shower products are made from different materials to comply with the needs of the market with regard to design and functionality. To avoid damage to the product, it is necessary to take proper care of it. For best results: • Prevent the buildup of mineral scale and /or soap residue by cleaning your Hansgrohe product(s) when needed. • Select a cleaning agent specifically intended for the type of product. • Do not use these types of cleaners as they will cause damage to your Hansgrohe product: Any cleaning agent containing hydrochloric acid, formic acid, lye, or acetic acid. Abrasive cleaning powders, pads, or brushes. Steam cleaners. “No rinse” cleaning agents. • Always follow the instructions provided by the manufacturer of the cleaning agent. • Do not mix cleaning agents, unless directed by the manufacturer. • Do not spray cleaners directly onto the product as drops could enter openings and gaps and cause damage. When using spray cleaners, spray the cleaner onto a soft cloth or sponge. • Always rinse your Hansgrohe product thoroughly with clear water and polish dry with a soft cloth after cleaning. Important • Residue from soaps and shampoos can cause damage. Rinse the product with clean water after each use.
- Page 13 • Ne pulvérisez pas les nettoyants directement sur le produit car des gouttes pourraient entrer dans les ouver- tures et les fentes et causer des dommages. Lorsque vous utilisez des nettoyants par pulvérisation, pulvérisez le nettoyant sur un chiffon ou une éponge douce. Important • Le résidu provenant des savons et des shampoings peut causer des dommages. Rincez le produit avec de l'eau propre après chaque utilisation. • Le résidu provenant des nettoyants pour cuvette/baignoire/carrelage peut endommager les robinets et les raccords de tuyauterie. Rincez immédiatement toute surpulvérisation sur le produit Hansgrohe. • De meme, il est interdit de stocker des detergents ou des produits chimiques sous les produits, par ex. dans un meuble sous lavabo, car les vapeurs qui s'en degagent risquent d'abimer les produits. • Les dommages au produit causés par un mauvais entretien ou par l'utilisation de produits de nettoyage inadéquats ne sont pas couverts par la garantie. • Si un composant du produit est endommagé, remplacez-le, car il existe un risque de bles- sure.
-
Page 14: Limited Consumer Warranty
Limited Consumer Warranty This product has been manufactured and tested to the highest quality standards by Hansgrohe, Inc. (“Hansgrohe”). This warranty is limited to Hansgrohe products that are purchased by a consumer in the United States or Canada after March 1, 1996, and installed in either in the United States or in Canada. WHO IS COVERED BY THE WARRANTY This warranty extends to the original purchaser only. This warranty is non-transferable. WHAT IS COVERED BY THE WARRANTY The warranty covers only your Hansgrohe manufactured product. Hansgrohe warrants this product against defects in material or workmanship as follows: Hansgrohe will replace at no charge for parts only or, at its option, replace any product or part of the product that proves defective because of improper workmanship and/or material, under normal installation, use, service and maintenance. If Hansgrohe is unable to provide a replacement and repair is not practical or cannot be made in timely fashion, Hansgrohe may elect to refund the purchase price in exchange for the return of the product. LENGTH OF WARRANTY Replacement or repaired parts of products will be covered for the term of this warranty, as stated in the following two sentences. If you are a consumer who purchased the product for use primarily for personal, family or household purposes, this warranty extends for as long as you own the product and the home in which the product is originally installed. If you purchased the product for use primarily for any other purpose, including, without limitation, a commercial purpose, this warranty extends only (i) for 1 year, with respect to Hansgrohe & Commercial products, and (ii) for 5 years, with respect to Axor products. THIS WARRANTY DOES NOT COVER, AND HANSGROHE WILL NOT PAY FOR: A. Conditions, malfunctions or damage not resulting from defects in material or workmanship. - Page 15 EXCLUSIONS AND LIMITATIONS REPAIR OR REPLACEMENT (OR, IN LIMITED CIRCUMSTANCES, REFUND OF THE PURCHASE PRICE) AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE PURCHASER. HANSGROHE NEITHER ASSUMES NOR AUTHORIZES ANY PERSON TO CREATE FOR IT ANY OTHER OBLIGATION OR LIABILITY IN CONNECTION WITH THIS PRODUCT.
