- Page 1 Installation Instructions / Warranty Talis C 14111xx1 Talis C 14116xx1 Talis C 14120xx1...
- Page 2 14111xx1 14120xx1 14116xx1...
-
Page 3: Technical Information
English Technical Information Recommended water pressure 15 - 75 PSI Max. water pressure 145 PSI Recommended hot water temp. 120° - 140° F* Max. hot water temp 176°F* Flow rate - lavatory 1.5 GPM Flow rate - bidet 2.2 GPM Hole size in mounting surface 1⅜"... -
Page 4: Données Techniques
Français Español Données techniques Datos tecnicos Presión recomendada en servicio 15 - 75 PSI Pression d’eau recommandée 15 - 75 PSI Presión en servicio max. 145 PSI Pression d’eau maximum 145 PSI Temperatura recomendada del 120� - 140� F* Température recommandée 120°... - Page 5 Replacement Parts / Pièces détachées / Repuestos 14191xx0 96338000 98863xx0 98864000 13192xx0 95140000 97685000 98865000 92036xx0 98866000 96321001 - 18" 96316001 - 35" 96657xx0 88509xx0 88744xx0 13961000 xx = finish / couleurs / acabados chrome oil rubbed bronze brushed nickel rubbed bronze...
-
Page 6: Installation
English Installation Install the drain pull rod on the faucet. Position the faucet and sealing ring on the mount- ing surface. Install the fiber washer, friction washer and mount- ing nut (1). Tighten the mounting nut (2). -
Page 7: Instalación
Français Español Installation Instalación Installez la tirette. Instale el tirador. Placez le robinet et l’anneau d’étanchéité sur la Coloque el grifo y el aro de sellado sobre la surface de montage. superficie de montaje. Installez la rondelle en fibre, la rondelle métallique Instale la arandela de fibra, la arandela metálica et l’écrou de montage (1). - Page 8 English Tighten the tensioning screws. Connect the hoses to the stops. Use two wrenches, as shown, to prevent hose twisting. Install the pop-up drain. Turn on the water and check all connections for leaks. Set the high temperature limit stop (optional).
- Page 9 Français Español Serrez les vis de pression à l’aide d’un tournevis. Apriete los tornillos tensores con un destornillador. Conecte las mangueras de suministro de agua Connectez les tuyaux d’arrivée d’eau chaude et caliente y fría a los topes. d’eau froide aux les butées d’arrêt. Use las dos llaves fijas como se ilustra, Utilisez deux clés, tel qu’illustré.
-
Page 10: Installation / Installation / Instalación
Installation / Installation / Instalación Petroleum-based plumbers Le mastic de pétrole-basé Masilla de petróleo-basó putty can damage the surface peut endommager la surface puede dañar la superficie de of some sinks. Please consult de quelque baignoires. S'il algún bañeras. Consulte por the manufacturer of the sink regard- vous plaît consulter le fabricant favor al fabricante del bañera con... - Page 11 Set the High Temperature Limit Stop (optional) / Réglage de la butée limite d’eau chaude (en option) / Ajuste el tope de límite de alta temperatura (opcional)
- Page 12 User Instructions / Instructions de service / Manejo ouvert abierto fermé cerrar cold chaud froid caliente frío Cleaning / Nettoyage / Limpieza...
- Page 13 Cleaning Recommendation for Hansgrohe Products Modern bathroom faucets, kitchen faucets and shower products are made from different materials to comply with the needs of the market with regard to design and functionality. To avoid damage to the product, it is necessary to take proper care of it.
-
Page 14: Indications Importantes
le chiffon (torchon, éponge) et effectuer comme cela le nettoyage, car les aérosols peuvent pénétrer dans les ouvertures et fentes de la robinetterie et peuvent provoquer des détériorations. • Après le nettoyage rincez avec suffisamment d’eau claire pour éliminer les restes de produits attachés. •... -
Page 15: Limited Consumer Warranty
Limited Consumer Warranty This product has been manufactured and tested to the highest quality standards by Hansgrohe, Inc. (“Hansgrohe”). This warranty is limited to Hansgrohe products that are purchased by a consumer in the United States or Canada after March 1, 1996, and installed in either in the United States or in Canada. WHO IS COVERED BY THE WARRANTY This warranty extends to the original purchaser only. - Page 16 When warranty service is completed, any repaired or replacement product or part will be returned to you postage prepaid. EXCLUSIONS AND LIMITATIONS REPAIR OR REPLACEMENT (OR, IN LIMITED CIRCUMSTANCES, REFUND OF THE PURCHASE PRICE) AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE PURCHASER. HANSGROHE NEITHER ASSUMES NOR AUTHORIZES ANY PERSON TO CREATE FOR IT ANY OTHER OBLIGATION OR LIABILITY IN CONNECTION WITH THIS PRODUCT.
