CAUTION:
• Never connect an electric power tool with an
input power exceeding that specified in the "
SPECIFICATIONS " to the socket of the cleaner
by turning the suction force adjusting knob.
Connecting the electric power tool exceeding
the specified input power may cause overheat
and damage to the cleaner. Refer to the specifi-
cations to avoid this.
The cleaner can be connected to an electric power tool
up to input power shown in the " SPECIFICATIONS ".
To connect an electric power tool, open the cap and
insert the power tool plug into the socket of the cleaner.
► Fig.4: 1. Suction force adjusting knob 2. Switch
lever
Rotate the switch lever to the " AUTO " position.
Move the suction force adjusting knob to the position
suitable for the input power of the electric power tool
you intend to use. Refer to the SPECIFICATIONS for
the relation between suction force adjusting knob and
the electric power tool input power.
Switching on and off of the connected electric power
tool simultaneously brings the cleaner switching on and
off action. The cleaner still works for a few seconds
even after the electric power tool is switched off.
After use, disconnect the power tool from the socket of
cleaner.
Switch off the cleaner after use.
Auto-suction stop during suction
operation
WARNING:
Do not use for a long time while the float is at
•
work. Using the cleaner with its float at work for
a long time can cause overheat, resulting in the
cleaner deformation.
• Do not pick up foam or soapy liquid. Picking
up foam or soapy liquid can cause foam to come
out of air exit before the float works. Continuing
to using in this condition may cause an electric
shock and breakage of the cleaner.
The cleaner has a float mechanism that prevents water
from immersing into the motor when picking up more
than a certain amount of water.
When the tank is full and the cleaner no longer picks up
water, switch off the cleaner and empty the tank.

Installing the holder

► Fig.5: 1. Holder
When connecting an electric power tool, secure the
power supply cord and hose using the holders at a 70
cm - 80 cm distance among the holders that are pro-
vided with the cleaner so that the hose is not entangled
by the power supply cord.
Usage of base hook
CAUTION:
• Be careful not to pinch your fingers when
closing the base hook. Failure to do so may
cause personal injury.
NOTE:
• Do not apply an excessive force on the base
hook. The excessive force on the base hook
may damage the base hook. Close the base
hook when not in use.
Opening the base hook allows the following usage.
Storing the power supply cord
NOTE:
• Do not use the cleaner or a connected elec-
tric power tool with a power supply cord
wound on the base hook. Using the cleaner
or the connected electric power tool with power
supply cord may cause damage the power
supply cord.
► Fig.6: 1. Power supply cord 2. Base hook
Storing the front cuffs
Front cuffs 22, 24 and 38 can be stored (up to two at a
time.)
► Fig.7: 1. Front cuffs
Storing the hose
► Fig.8: 1. Hose
Resting a reasonable size of electric
power tool for the base hook, such
as circular saw.
► Fig.9
Locking or unlocking the caster
For Models VC1310L and VC2510L
► Fig.10: 1. Caster 2. Stopper lever 3. FREE position
4. LOCK position
For Model VC3210L
► Fig.11: 1. Caster 2. Stopper lever 3. FREE position
4. LOCK position
To lock the caster with a stopper, lower the stopper
lever and the caster no longer will rotate. To release the
caster from the locked position, raise the stopper lever.
Locking the caster is convenient when storing the
cleaner, stopping the work on the way and keeping the
cleaner still.
To operate the stopper, move it by hand.
NOTE:
• When moving the cleaner, make sure that the
caster is unlocked. Moving the cleaner with the
caster in the locked position may cause damage
to the caster.
12 ENGLISH
