4.2

Performing Recovery Operations using Power Button

Network administrators can perf orm recovery operations using the power button on the rear panel
of RXV81.
Note: Besides this recovery option, Android devices also f eature an independent, automatic
problem detection and recovery attempt capability that can culminate in recovery mode or in
switching image slots.
The f ollowing f igure shows the power button.
➢
To perform recovery operations:
1. Disconnect the power cord f rom RXV81 while long-pressing the power button f or as long as is
required f or the action (see
- and durations – see the Long-press for column).
2. Reconnect the power cord and continue pressing the power button f or however long is
necessary.
Table 4-1: Recovery Operation Options using RXV81's
Stage
On Uboot
3. Short-press the power button to move down the menu options, and long -press to select an
option.
User's & Administrator's Manual
Table 4-1
Action
NOTHING
ENTER_RECOVERY
SWITCH_AB_SLOT
ENTER LOADER
RESTORE_DEFAULT
SHUTDOWN
below f or the available actions - see the Action column
Long-press for
< = 2 seconds
2-4 seconds
4-6 seconds
6-8 seconds
8-10 seconds
> = 10 seconds
34
RXV81 USB Peripheral
Power Button
LED
Flashes 3x
RED
WHITE
BLUE
BLUE + WHITE
Document #: LTRT-18260
