8" SINGLE CARTRIDGE HOUSING
All information included in this publication is based on the latest information available at the
time of printing. Pentair reserves the right to make changes at any time without notice and
without incurring any obligation whatsoever. Photocopying of this publication by authorized
original equipment manufacturers who have purchased directly from Pentair, or by persons
using the materials for legitimate educational purposes, is approved by Pentair. Otherwise all
copyright protection afforded by the law applies.
Product Bulletin: 98760 Rev C
USER'S GUIDE
80AQ15 (Non-ASME)
150
PSI
Goa, India. Phone: 91-832-6754400  Fax: 91-832-6754412
www.codeline.com
ECN No. 6139 Revision dated : 09/06/2023
0
