USER'S GUIDE
End Ported Membrane Housings
MODEL – 40E30N
All information included in this publication is based on the latest information available
at the time of printing. Pentair reserves the right to make changes at any time without
notice and without incurring any obligation whatsoever. Photocopying of this
publication by authorized original equipment manufacturers who have purchased
directly from Pentair, or by persons using the materials for legitimate educational
purposes, is approved by Pentair. Otherwise all copyright protection afforded by the
law applies.
Product Bulletin – 526003 -Rev. D
CodeLine
Goa, India. Phone: 91-832-6754400  Fax: 91-832-6754412
www.codeline.com
ECN No. 6139 Revision dated – 09/06/2023
Page 1 of 11
