USER'S GUIDE
End Ported Membrane Housings
For Reverse Osmosis
All information included in this publication is based on the latest information available
at the time of printing. Pentair reserves the right to make changes at any time without
notice and without incurring any obligation whatsoever. Photocopying of this
publication by authorized original equipment manufacturers who have purchased
directly from Pentair, or by persons using the materials for legitimate educational
purposes, is approved by Pentair. Otherwise all copyright protection afforded by the
law applies.
Product Bulletin – 526004 -Rev. B
CodeLine
MODEL – 40E60
Goa, India. Phone: 91-832-6754400  Fax: 91-832-6754412
www.codeline.com
ECN No. 6139 Revision dated – 09/06/2023
Page 1 of 11

Advertisement

loading
Need help?

Need help?

Do you have a question about the CODELINE 40E60 and is the answer not in the manual?

Questions and answers

Summary of Contents for Pentair CODELINE 40E60

  • Page 1 MODEL – 40E60 All information included in this publication is based on the latest information available at the time of printing. Pentair reserves the right to make changes at any time without notice and without incurring any obligation whatsoever. Photocopying of this...
  • Page 2 DANGER – HIGH PRESSURE DEVICE This vessel may cause loss of life, severe bodily harm, or property damage if not correctly installed, operated and maintained. Read and understand all guidelines given in this bulleting before attempting to open, operate or service this vessel. Failure to follow these guidelines and observe every precaution will result in malfunction and could result in catastrophic failure.
  • Page 3: Installation

    INSTALLATION Regardless of when or by whom your vessel may have been installed, there are a few quick checks you should make before use. Check that each vessel is: • Mounted with compliant material (Polyurethane saddle) between the fiberglass shell and any rigid frame.
  • Page 4 OPENING THE VESSEL This can also be accomplished using a WARNING screwdriver and a pair of pliers if the tool is not Relieve pressure from vessel readily available. before beginning this procedure. With the removal tool the retaining ring can Contamination Removal be lifted upward by simply rotating the tool Metal oxidation products and mineral...
  • Page 5 OPENING THE VESSEL (CONTD…) Once the retaining ring has been removed, examine the area for burrs or dings which could damage the head or membrane. If necessary, use ScotchBrite or 600 grade sandpapers to smooth the area. Removing Head Assembly – 1.
  • Page 6: Replacing Elements

    A sharp, forceful thrust may be needed manufacturer Pentair Water to enter plug seal into the vessel bore. clarification. Removing Elements 1. Remove heads from both ends of vessels as described in Opening the Vessel.
  • Page 7 REPLACING ELEMENTS (CONTD…) 7. Lubricate element seals sparingly with the element manufacturers recommended lubricant or with glycerin. 8. Insert each element with the brine seal (typically a U-cup seat) installed on the upstream end with its lip facing upstream. CAUTION System malfunctions and element damage may result if elements are installed in the wrong direction.
  • Page 8: Head Assembly

    HEAD ASSEMBLY NOTE Head Rebuilding should be performed in a clean work area. Dust or dirt on O-rings or other parts can scratch inner surfaces, with subsequent leakage. 1. Using a small screwdriver or similar tool 2. Using a small screwdriver or similar tool remove the Plug Seal.
  • Page 9 HEAD ASSEMBLY (CONTD…) 1. Use only head components in as-new condition. Use new O-rings each time the 4. Insert the Head Seal O-ring into the head is assembled. groove on the outside diameter of the End Plug. 2. Cover O-rings with a this even layer of Parker Super O-Lube...
  • Page 10: Warranty

    : Use of components damaged by corrosion can cause catastrophic failure. Seals should be replaced as necessary each time the vessel is serviced. Any parts that need to be replaced are available from your supplier or from Pentair. NOTE AFTER END OF SERVICE LIFE OF VESSEL, DISPOSE THE VESSEL AND ITS COMPONENTS AS PER APPLICABLE LOCAL LAWS AND REGULATIONS WARRANTY TERMS &...
