- Page 1 Guangzhou Micro-shot Technology Co., Lt ML10 Biological Microscope User Manual www.m-shot.com Tel：0086-020- 38262481 Fax：0086-020- 38262491...
- Page 2 The ML10 series microscope equipped with achromatic objective or cost effective plan achromatic objective, wide field view eyepiece, using trinocular, binocular or monocular observation tube, optical system imaging vision is clear and broad. The system is widely used in biology, medicine, agriculture and other fields, it is an ideal instrument for medical treatment, teaching and scientific research.
- Page 3 5. Stage moving range: vertical 35 mm, transverse 75 mm. 6. Fine focus adjustment: 0.002 mm. 7. Coarse focus adjustment: 53-75 mm. 8. Light source: 6V20W halogen lamp (brightness adjustable). 9. Power supply : AC 220V (50HZ) or AC 110V (60HZ) can be selected. 10.
- Page 4 Figure 1 1. ocular 2. verticle focus wheel 3. horizontal move wheel 4. power 5. brightness control knob 6. condenser 7. condenser fix screw 8. stage 9. nosepiece 10. trinocular Figure 2...
- Page 5 1. eyepiece 2. objective 3. slider holder 4. condenser（with aperture diaphragm）5. condenser lifting wheel 6.fine and coarse focus system 7. fine focus wheel 8. body 9. tube fix crew 10. binocular Ⅲ. Installation...
- Page 6 Figure 3 1. eyepiece 2. binocular (ocular or trinocular) 3. nosepiece 4.objective 5. condenser fix screw 6. condenser （with aperture diaphragm）7. Tube fix screw Ⅳ. Operation guide 1. Press the power switch to the "I" side to turn on the power. 2.
- Page 7 3. Fine and coarse focus system Fine and coarse focus system has one coaxial and rail guide ① fine focus hand wheel ② coarse focus hand wheel. Figure 6 图 6 4. Stage Specimen holder and stage ① convenience to hold specimen ② vertical moving hand wheel ③...
- Page 8 7. Condenser aperture diaphragm Aperture diaphragm hand wheel ⑤ used to adjust field view of number for microscope lighting. Observe pupil inside objective after taking off the eyepiece ① diaphragm shape on bright ring, switch aperture hand wheel ⑤ adjust diaphragm size ② normally the diaphragm size is the Figure 9 best when gets to objective pupil...
-
Page 9: Ⅵ、Maintenance
Ⅵ、MAINTENANCE 1. Sweep the lens Sweep the lens by lens tissue or soft fabric immersed with mixed liquid of alcohol/ether or diethyl benzene. Cleaning the oil on the 100X objective whenever finish operating. 2．Clean the painted parts The dust on the painted parts can be removed by gauze, for the grease spots, the gauze immersed slightly with aviation gasoline is recommended.
