- Page 1 User Manual MI-BGU-LED-CKX53 Inverted LED Fluorescence Illuminator...
- Page 2 Thank you for buying our product! This unit is a precision optical instrument. Our product has been design to provide the highest level of safety, however, improper operation or negligence in following the instructions in this manual may cause personal injuries and property losses. In order to ensure your safety, prolong the life of this unit and maintain it properly, please read this manual carefully before operating this unit.
- Page 3 Content Ⅰ. Introduction........................1 Ⅱ. Specification.........................2~3 Ⅲ. Installation ......................... 3~4 Ⅳ. Operation........................5~6...
-
Page 5: Ⅰ.introduction
Ⅰ.Introduction The MSHOT MI-LED series LED fluorescence attachment takes us of long working life LED as light source, can easily expand Olympus CKX53 microscope into an energy-saving, efficient, easy to operate and super long-life LED lighting fluorescence microscope and do not effect original bright field observation. -
Page 6: Ⅱ.specification
MI-BGU-LED Ⅱ.Specification 1. Specification Excitation Excitation group LED wavelength Dichroic mirror Emmision filter wavelength 475/30nm 505nm 535/40nm 470-475nm 540/25nm 565nm 605/55nm 530-535nm 375/30nm 415nm 460/50nm 365nm... -
Page 7: Ⅲ.installation
2. Optional specification Excitation Excitation group LED wavelength Dichroic mirror Emmision filter wavelength 330-380nm 400nm 420nmLP UV(LP) 365nm 460-490nm 505nm 510nmLP B(LP) 470-475nm 510-550nm 570nm 575nmLP G(LP) 530-535nm Y(optional) 560nm 540-580nm 600nm 610nmLP Ⅲ.Installation Unpack and take out the corresponding accessories, including LED fluorescence module, power adapter, fluorescence module fixed base plate LED fluorescence module Fluorescence module fixed base plate... - Page 8 ❶Adjust the coarse focusing screw to raise the objective lens, take out the two screw hole plugs on the bottom plate, loosen the screws with a hexagonal key, and take the bottom plate from the microscope. Push in fluorescent module fixed bottom plate on the microscope base, and the bottom plate is fixed on the microscope by tightening the screws.
-
Page 9: Ⅳ.operation
Ⅳ.Operation Plug in the power adapter cable and plug the other end of the power adapter into the power socket. ① Turn the switch / brightness adjustment knob to hear the sound of "click", that is, the light source has been turned on. Continue to turn the knob to increase the brightness. - Page 10 Mark Channels Empty for bright field observation Blue LED excitation Green LED excitation UV LED excitation Attentions: 1. The brightness of the LED in the illuminator can be adjusted freely according to the difficulty of excitation of the observed sample; generally, lower than the full load current is beneficial to prolong the service life of the LED lamp bead;...
