- Page 1 MZX81 (MZX-BG-LED) Stereo Fluorescence Microscope User manual...
-
Page 2: Table Of Contents
Content Advantages..........................2 Ⅰ. Specification........................3 Ⅱ. Construction........................4 Ⅲ. Installation........................5 Ⅳ. Operation........................6 Fluorescence observation....................6 Bright field observation......................6 Ⅴ.Maintenance........................7 - 1 -... -
Page 3: Advantages
MZX81 fluorescence stereo microscope using Galilean optical system, LED double epi-illumination light path design, matching Blue and Green color LED excitation light source, to achieve high-resolution and high-quality fluorescence imaging. Advantages： Standard blue and green excitation groups to satisfy most scientific research requirement, accept to customize wavelength. -
Page 4: Ⅰ. Specification
Ⅰ. Specification Optical system Galilean optical system 3W LED Blue LED wavelength 470-475nm LED epi-fluorescence Blue filter set:EF 460-490nm/DM 500nm/BF 520nm； illumination Green LED wavelength 520-530nm Green filter set：EF 510-550nm/DM 570nm/BF 590nm - 3 -... - Page 5 SZX-TR30 lead-free observation head Trinocular, 30° inclination light path mode: eyepiece 100%，photography 80%, eyepiece 20% Observation tube - 4 -...
-
Page 6: Ⅱ. Construction
Eyepiece SWF 10X ,F.N. 20 Zoom radio: 7:1（0.8×~5.6×） Zoom system Screw fixed objective mode 1X，N.A. 0.10， WD. 81mm Objective SZ2-ST standard base，with fluorescence plate M-FL Basement Transmitted fluorescence accessories SZ2-ILA、H-150（optional） Room temperature：5°C to 40°C（41°F to 104°F）,Maximum relative Working surroundings humidity is 80％，temperature is 31°C Ⅱ. - Page 7 2.C-mount interface 1.Eyepiece 3.observation shift lever 4. Set screw 6.Brightness adjustment knob （Left side） 5. Filter set turret 7. DC power adapter seat （Back side） 8. Set screw 9. Light source transfer lever 10. Zoom rotary knob 11. Manual crew Focusing system 13.
-
Page 8: Ⅲ. Installation
Ⅲ、Installation Trinocular head MZX-BG-LED fluorescence attachment Installation steps as image: Zoom system 1.Mount zoom system to base,fix with manual screw (11 in the image). 2.Mount MZx-BG-LED fluorescence attachment to the zoom system, fix with set screw (8 Base in the image) 3.Mount trinocular head to the fluorescence attachment, fix with... -
Page 9: Ⅳ. Operation
Ⅳ. Operation Fluorescence observation: 1. Connect power adapter 13 is connected to a DC power seat 7, get on power. 2. Turn the brightness adjustment switch knob 6, you can hear "ding" sound. 3. The observation needs to select the corresponding excitation group, switching the light source lever 9 to select LED excitation source, adjust the filter set turret 5 to select the corresponding filter group. -
Page 10: Ⅴ.maintenance
Ⅴ. Maintenance 1. Wipe the lens Wipe the lens can be used with alcohol / ether mixture or xylene lens paper or cotton flower. 2. Wipe painted surfaces Wipe painted surfaces, used gauze to remove dust. If grease dirt removed with gauze soaked some gasoline, not with an organic solvent: Wipe painted surfaces and plastic parts (such as alcohol, ether and other diluent).
