- Page 1 Guangzhou Micro-shot Technology Co., Ltd Inverted LED Fluorescence Attachment MI-BGU-LED IX50/IX70 User Manual Website:www.m-shot.com...
- Page 2 Email: sales@mshot.com...
- Page 3 Thank you for buying our product! This unit is a precision optical instrument. Our product has been design to provide the highest level of safety, however, improper operation or negligence in following the instructions in this manual may cause personal injuries and property losses. In order to ensure your safety, prolong the life of this unit and maintain it properly, please read this manual carefully before operating this unit.
- Page 4 Content I. Main parts........................01 II. Specification.........................02 Ⅲ. Components........................03 Ⅳ. Installation......................04~05 Ⅴ. Note..........................05...
- Page 5 I. Main parts Name Quantity Unit Attachment body Power adapter piece Light barrier piece II. Specification EX480/40nm DM505nmLP EM510nmLP B excitation group EX530/40nm DM570nmLP EM590nmLP G excitation group EX360/50nm, DM400nmLP EM420nmLP UV excitation group 3W LED cold light Light source Fluorescence, bright field Observation Pull-push at three positions ( Blue, green, bright field)
- Page 6 Ⅲ. Components Light port Lever Brigthness knob Fix slot vents Power plug Instructions： Light port - Let fluorescence illuminating light pass Power plug - Connect AC adapter to supply power Brightness knob- Used to adjust fluorescence lighting brightness Lever- Move BGU filter groups and lamps Vents- Heat transmission Fix slot - Screw to fix the attachment body...
- Page 7 Ⅳ. Installation 1. Unpack MI-BGU-LED illuminator and power adapter. 2. If the microscope already has attachment under the condenser, please take it off. Find the plastic box on right hand of the microscope as image 01 and take off it slightly. Image 01 3.
- Page 8 4. Lock the screw on the right side of the main body of the microscope (fix slot) with a hexagonal screwdriver as image 04. Image 04 5. Connect the power adapter to the illuminator and power on to start use.Push or pull lever to change fluorescence filter cube among blue, green, UV and bright field Image 05 Ⅴ.
