14 FT 2-PIECE ROUND ALUMINUM ARM KITS
These kits are designed for use on a 1601 or 1603 barrier gate operators ONLY. These kits have 2-7 ft arms that assemble into a
14 ft arm. ONLY the 1601-528 kit has 2 extra holes on the arm that allow connection to a DoorKing break-away bracket if desired.
Assemble Arm
F i r
s t 7
F t A
r m
Warning
Label
Note: 1601-528 kit has 2 holes
on the end of ONE arm section to
attach the DoorKing break-away
bracket to (Sold Separately).
Installation
1. Insert the coupler half-way into the first arm and secure with the supplied screws through the
pre-drilled holes. The warning labels MUST be in the middle of the arm.
2. Insert the coupler into the second arm being sure to align the red/white stripes and secure through
the pre-drilled holes. DO NOT INSERT COUPLER INTO THE SECOND ARM UNTIL THE FIRST ARM is
SECURED TO THE COUPLER WITH THE SUPPLIED SCREWS THROUGH THE PRE-DRILLED HOLES!
1601-526-E-5-24
Self-tapping screws
through pre-drilled
holes in arm.
A l u
m i
n u
A r m
s S
F i r
s t 7
F t A
r m
Warning
Copyright 2024 DoorKing
Attach and secure coupler to one side of the
arm before inserting it into the other arm.
Note: Holes are pre-drilled in the arm halves,
but not in the coupler.
m
C o
l i d e
u p
1 / 2
W a
l e r
y O
n
Match red/white stripping
and be sure warning labels
are in the middle of the arm
and visible from both sides.
Label
®
, Inc. All rights reserved.
1
DoorKing Part Numbers
1601-524
Standard 2-Piece Arm 2-Piece Break-Away Arm
Note: Drawings not to scale
Self-tapping screws
through pre-drilled
holes in arm.
S e
c o
n d
S e
c o
n d
7 F t
A r m
120 S. Glasgow Avenue
Inglewood, California 90301
1601-528
7 F t
A r m
U.S.A.
