Sennheiser SDC 8200 CU Datasheet

Digital Conference and Interpretation System
SDC 8200 CU/CU-M
SDC 8200 is the solution you
are looking for. Fully digital,
the system sets new standards
in professional conference
flexible communications solution
– a sound investment that pays
off, again and again. SDC 8200 is
available in a number of variants
catering to different needs.
Regardless of requirements –
whether you are hosting a small
conference or a large congress
– there is always a suitable SDC
system for your application.
Technical Data SDC 8200 CU
Cat. No. 500867
Max. number of 120
conference terminals
Can be used with yes
SDC 8200 DV
Cascadable yes (system max.:
1024 conference
terminals)
Language channels 4/8/28 (depen-
ding on licence)
Interpreter units 1 to 8
per language
Supported voting one out of three,
modes one out of five
Camera and media yes
control
Connection of SDC up to 4
8200 AO
Control software SDC 8200 SYS
technology. SDC 8200 is a
SDC 8200 CU-M
500860
50
no
no
4
2
one out of three
yes
no
SDC 8200 SYS-M
across boundaries
SDC 8200 CU/CU-M
The heart of every system. These central units feature a host
of control functions plus all the connection sockets required
for the delegate units, additional audio sources, monitoring
headphones, PC, interpretation management and camera
control. While the SDC 8200 CU is the ideal choice for large
international conferences with many hundreds of delegates
(several CU can be connected together for very large systems),
the SDC 8200 CU-M has been designed for smaller applications;
it has a limit of 50 terminals and four interpreted language
channels with a maximum of two interpreter units per language.
Wheel for menu selection

COM 1 to COM 3 serial interfaces for PC and media control

Communication
