Sennheiser SDC 8000 DC Product Sheet

SDC 8000 DC
Conference and Information Systems |
General Description
The digital SDC 8000 DC delegate unit is an ideal choice for both mobile and fixed
conference systems. Its compact and elegant design harmoniously blends in with
any conference room. The unit features a high-quality built-in loudspeaker, provid-
ing excellent sound at a pleasant volume. By pressing the Mic key, the conference
participants can either switch on the microphone or signal their request to speak.
The SDC 8000 DC delegate unit can be used by two participants as it features two
independent headphone sockets, each fitted with a channel display and channel
selection keys for choosing a translated language independent of each other.
Features
Built-in high-quality loudspeaker (automatically muted when the
microphone is switched on)
Microphone on/off (request) key
Gooseneck microphone with red LED ring
Two RJ 45 sockets for connecting up to 15 units in one cable line
Two 3.5 mm headphone jacks for headphones or induction couplers
for the hearing impaired
Two separate headphone volume controls
Two separate sets of channel selection keys with numerical display of the
selected channel (floor language + up to 28 translations)
Delivery Includes: 1 SDC 8000 DC Delegate Unit
Accessories
RJ 45 conference bus cables, type 24 AWG,
available lengths: 2 m, 3 m, 5 m, 10 m, 20 m, 50 m
HD 410-D, HD 1029 headphones
SDC 8000
Technical Data
Frequency response ................................. 100 – 14,000 Hz
Pick-up pattern .........................................................cardioid
Headphone connector................... 3.5 mm mono (>32 Ω)
Power supply.............................................................. 48 V DC
Power consumption............................................max. 3.9 W
Operating temperature .........................................0 – 50 °C
Standards..................................................................... IEC 849
Colour..........................................................Pantone Black 7C
Housing .............................................................................. ABS
Dimensions ............................................ 150 x 80 x 185 mm
Gooseneck length .................................................... 380 mm
Weight ............................................................................. 620 g
Cat. No. 009413
