Sennheiser SDC 8000 AO Product Sheet

SDC 8000 AO
Conference and Information Systems |
General Description
Connected to the SDC 8000 CU central unit, the SDC 8000 AO analog output unit
features 9 analog outputs to deliver the floor language plus eight translations to IR
modulators, PA equipment, recording equipment etc. The SDC 8000 AO is powered
via the central unit.
Features
Audio interface provides the fl oor language channel plus eight interpreted
language channels to recording equipment, PA systems or infra-red
transmission systems
Phoenix connector for remotely switching a recording unit on or off
LEDs
Power LED
Sync. LED for data synchronisation
Floor LED for indicating an active microphone
Connections
9 transformer balanced XLR-3M output sockets for the fl oor language
and eight translations
2 unbalanced RCA phono output sockets for the fl oor language
(conference channel)
8 unbalanced RCA phono output sockets for eight translations
(interpreter channels)
4-pin Phoenix connector for switching external units
1 RJ 45 socket for connecting the output unit to the SDC 8000 CU central unit
1 RJ 45 socket for connecting an additional SDC 8000 AO
(up to four output units can be daisy chained)
SDC 8000
Technical Data
Power supply............................... 48 V DC via SDC 8000 CU
Power consumption......................................................1.6 W
Frequency response ................................. 100 – 14,000 Hz
Audio connectors ................ 9 x XLR-3M; 10 x RCA phono
Output level..........................................................max. 0 dBu
Output impedance....................................... < 80 Ω (1 kHz)
Operating temperature .........................................0 – 50 °C
Dimensions ............................................485 x 46 x 186 mm
Weight ............................................................................ 2.7 kg
Cat. No. 009419
DATA OUT port
