Sennheiser SDC 8000 ID Product Sheet

SDC 8000 ID
Conference and Information Systems |
General Description
Designed according to international standards, the SDC 8000 ID interpreter unit is an
ideal choice for large, international conferences with up to 28 translated languages
and up to eight interpreter units per booth. The SDC 8000 ID is extremely easy to
use. All important information and settings are shown on a back-lit graphic LCD
display. The incoming languages can be chosen via three configurable relais keys.
A language quality indicator marks the language which has been translated several
times, thus avoiding possible information loss.
Features
Gooseneck microphone with red LED ring
Two 3.5 mm headphone jacks
Two RJ 45 sockets for connecting up to 15 units in one cable line
Three tone controls for volume, mid-range and treble
Built-in high-quality loudspeaker (automatically muted when a
microphone in the booth is switched on)
Loudspeaker volume control
Loudspeaker channel selection for incoming language
Three configurable relais keys for incoming languages
Two A and B output channels, channel selection key and "ENGAGED" LEDs
Configurable B channel
Back-lit graphic LCD display for relay languages, quality of relay languages,
loudspeaker language, set-up mode (only during basic configuration)
Large, red MIC key with LED
Mute key
Message keys with LED for displaying text messages
Delivery includes: 1 SDC 8000 ID Interpreter Unit
Accessories
RJ 45 conference bus cables, type 24 AWG,
available lengths: 2 m, 3 m, 5 m, 10 m, 20 m, 50 m
HD 410-D, HD 1029 headphones
SDC 8000
Technical Data
Frequency response ................................. 100 – 14,000 Hz
Pick-up pattern .........................................................cardioid
Headphone connector.................. 3.5 mm mono (> 32 Ω)
Power supply.............................................................. 48 V DC
Power consumption............................................... max. 4 W
Operating temperature .........................................0 – 50 °C
Standards...................................................ISO 2603; IEC 849
Colour..........................................................Pantone Black 7C
Housing .............................................................................. ABS
Dimensions ............................................ 150 x 80 x 185 mm
Gooseneck length .................................................... 380 mm
Weight ............................................................................. 675 g
Cat. No. 009418
