4.0 Reading from the appsCAN Module (SDO Read)
During configuration, it may be necessary to read certain locations in the Object Dictionary
(OD). This can be done with a Service Data Object (SDO) Read. The format for a (SDO
Read) is as follows:
byte 0
SDO Read Tx
CAN id
0x600+NID
OD lo = low byte of OD address
OD hi = hi byte of OD address
Sub = Subindex of OD address
A SDO Read will generate the following reply:
SDO Read Rx byte 0
CAN id
0x580+NID
Size = 0x4F (1 byte response)
0x4B (2 byte response)
0x43 (4 byte response)
OD lo = low byte of OD address
OD hi = hi byte of OD address
Sub = Subindex of OD address
Data0 always contains the Least Significant Byte (LSB) of the data present at the OD address.
Example: Read OD address 0x5008 subindex 0x32 in the module with NID = 0x10.
byte 0
SDO Write Tx
CAN id
0x610
The module will reply as follows:
SDO Write Rx byte 0
CAN id
0x590 0x4B
OD address 0x5008, subindex 0x32 of the module with NID = 0x10 contains the 2 byte value
0x2BC.
byte 1 byte 2
0x40 OD lo OD hi
byte 1 byte 2
Size OD lo OD hi
byte 1 byte 2
0x40 0x08 0x50
byte 1 byte 2
0x08 0x50
byte 3 byte 4 byte 5
Sub
byte 3 byte 4 byte 5
Sub Data0 Data1
byte 3 byte 4 byte 5
0x32
byte 3 byte 4 byte 5
0x32 0xBC 0x02
byte 6 byte 7
byte 6 byte 7
Data2 Data3
byte 6 byte 7
byte 6 byte 7
