Appendix D: LOCKing and unLOCKing dashCAN
When dashCAN is locked, its setup cannot be modified.
To LOCK dashCAN
1. Press SYS until "MOd" is displayed.
2. Press ↓ until "CONF" is displayed. Then press ENT.
3. Press ↓ until "LOCK" is displayed. Then press ENT.
4. "50" will be displayed. Press ↑ until "60" is displayed. Then press ENT.
dashCAN is now LOCKed.
To unLOCK dashCAN
1. Press SYS until "LOCK" is displayed. Then press ENT.
2. "50" will be displayed. Press ↑ until "60" is displayed. Then press ENT.
dashCAN is now unLOCKed.
If an unauthorized person learns that 60 is the key number, contact ECM.
Appendix E: General Information
Voltage Input: 11 to 25 VDC @ 250 mA
Terminal Assignments on Eurofast Connector:
1. Shield, 2. 11~28 VDC In, 3. Power Ground, 4. CAN_H, 5. CAN_L
Environmental: IP67, -55 to 125 °C, 100% humidity, module is sealed
Dimensions and Weight: 120 mm x 37 mm x 143 mm, 4 ¾" x 1 ½" x 5 ¾", (W x H x D)
244 gm, 8.7 oz
