ECM appsCAN Module Instruction Manual page 22

The appsCAN Kit consists of:
Description
1. appsCAN Control Module
2. Left (gray) connector with 300mm pigtails
3. Right (black) connector with 300mm pigtails
4. Flexi-Eurofast Cable
5. Eurofast "T"
6. Eurofast Terminating Resistor
7. 2m Eurofast 12mm Cable
8. DC Power Cable, DB9F, Banana
9. appsCAN Manual and Configuration software CD 13-01
Optional Cable Components:
1. Connector Kit
2 connectors, 2 locks, 24 terminals, 12 plugs
Note: Left (gray) connector is Deutsch P/N DTM06-12SA
Right (black) connector is Deutsch P/N DTM06-12SB
Lock for connectors is Deutsch P/N WM12S (2 required)
Terminals are Deutsch P/N 0462-201-2031
Plugs are Deutsch P/N 0413-204-2005
Crimper is Deutsch P/N HDT-48-00
All connectors, terminals, plugs, and crimper are available from Deutsch, Inc.
In the U.S.A., Deutsch products available from Ladd 1-800-223-1236.
Optional Power Supply:
1. AC/DC Power Supply, Universal 24VDC @ 4.2A 04-01
(requires P/N 11-17 Deutsch DTM3M to DB9F)
Optional CAN Adapter:
1. Kvaser Leaf Light, USB to CAN Adapter
18
P/N
02-05
11-22
11-23
09-04 (0.3m)
09-05
09-06
09-02
11-02
11-24
13-02
Quantity
1
1
1
1
1
1
1
1
1
1
1
1
