Multiway valve

Adjustment to the safety valve value
The pressure has been adjusted before leaving factory. Generally the user cannot adjust at will.
Take a rated capacity of 1200 kg as an example to state the adjusting procedures.
（1）Place 125% of rated load on the forks stably, that is 1500kg.
（2）Depress the accelerator pedal to the end, operate lifting and lowering control lever, if the
forks can be lifted to 0～300mm, the main relief valve pressure is right, otherwise follow step (3).
（3）If the forks cannot be lifted (off the ground), increase the main relief valve pressure by
removing the multi-valve cover and loosening the locking nut of main relief valve, screw the
adjusting bolt in clockwise; if the lifting height of forks is over 300mm, screw the adjusting bolt in
counterclockwise to reduce safety valve pressure accordingly.
（4 ） Depress the accelerator pedal to the end; lift the forks to a range from 0 to 300mm.
otherwise repeat the step 3 to meet the requirement.
Warning
·Goods must be placed stably;
·Once the pressure is set, please do not adjust casually.
Fault diagnoses and corrections
Fault
Pressure of relief
valve is not
steady or too low.
Mast tilt forward
when control
lever is used
while motor is off.
Mast is unstable
when tilting
forward.
The carriage is
downward when
the control lever
is in the neutral
position.
Spool valve is
unable to return
neutral position.
Leakage
Probable reason
Loose of pressure-adjust screw
Distorted or damaged pressure-adjust Replace
Worn or blocked relief valve element
Pump abated
Worn or damaged tilt lock valve
Broken tilting lock spring
Damaged tilt valve plunger O-ring.
Malfunctioning of tilt relief valve
Valve body and spool valve lever is
worn and their clearance is too great.
Spool valve lever is not in centre.
Cylinder seal abated.
Overload valve is worn or blocked by Replace or clean taper valve
Damaged or distorted reset spring.
Dirt exists between valve body and Clean.
Blocked control device.
Not coaxial parts at reposition
Damaged O-ring.
Faulty seal of joint.
Loose seal plate.
Loosed lock-nut of relief valve and
connect bolt between plate and plate.
Readjusted and retighten
Replace or clean
Examine and repair pump
Replace valve core and tilt lock
valve as an assembly
Replace spring
Replace O-ring
Replace tilt relief valve assembly
Replace
specified clearance.
Keep being in the centre
Examine and repair cylinder
Replace spring.
Adjust
Reinstall, be coaxial
Replace.
Check and retighten.
Clean seal plate and retighten
Tighten.
71
Corrective action
spool valve with
