Assa Abloy RIXSON 1351 Manual

1351
Gate Closer
PULL Side Mount ONLY
WARNING
This product can expose you to lead which is known to the state of
California to cause cancer and birth defects or other reproductive harm.
For more information go to www.P65warnings.ca.gov.
Right Hand PULL Side Shown
Dimensions are given in inches (millimeters).
Tools Needed
Copyright © 2013, 2020, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
1351IS Rev 2 09/20
55-1/8"
(1400mm)
Max
110-1/4"
(2800mm)
Max
ATTENTION:
An incorrectly installed or improperly adjusted
gate closer can cause property damage or
personal injury. These installation instructions
should be followed to avoid the possibility of
misapplication or misadjustment.
Approved 2020-09-14
Ce produit peut vous exposer au plomb qui, dans l'état de la Californie,
est reconnu pour causer le cancer, des anomalies congénitales ou d'autres
problèmes de reproduction. Pour plus d'informations, visitez:
www.P65warnings.ca.gov.
Included Components
Top Rail Plate x2
Closer Backplate x1
Closer
Bracket
Track x1
Track Pin x1
Closer x1
or
x4
Ø5.5 x 25
x4
Ø6 x 50
x2 x2
M6 x 14 M6 x 8
x2
x1
End Cap Guide
Arm x1
Cover x1
To Determine Your Hand of Door:
Push Side
Pull Side
Right Hand
PULL
x3
Top Rail Plate
x3
Hardware
x3
x4
Ø8 x 40
x2
M6 x 30
x2
x1
x1
x1
Left Hand
PULL
