Assa Abloy Norton 1600 Series Quick Start Manual

1600
Corrosion Resistant
Non Handed Door Closer
Regular Arm
Top Jamb Mount
Parallel Arm
WARNING
This product can expose you to lead which is known to the state of
California to cause cancer and birth defects or other reproductive harm.
For more information go to www.P65warnings.ca.gov.
Regular Arm
Right Hand Door - RH
Left Hand Reverse - LHR
Left Hand Door - LH
Right Hand Reverse - RHR
Included Components (See page 2 for mounting hardware)
Closer
Pinion Cap
1/8" Hex Wrench
Screw Pack
TO DETERMINE
HAND OF
To Determine Your Hand of Door:
YOUR DOOR:
Right Hand
Reverse
LEFT
HAND
DOOR
Copyright © 2016, 2020, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
80-9316-2535-020 Rev 3 04/20
Non Hold Open Arm Models
Right Hand Door - RH
Left Hand Reverse - LHR
Main Arm
Pinion Screw
Main Arm
Arm Assembly
To Identify Your Model:
Left Hand
Reverse
RIGHT
HAND
DOOR
Sized Adjustable
(Sizes 3,4) (Sizes 1-6)
1603BCSS
1604BCSS
Ce produit peut vous exposer au plomb qui, dans l'état de la Californie,
est reconnu pour causer le cancer, des anomalies congénitales ou d'autres
problèmes de reproduction. Pour plus d'informations, visitez:
www.P65warnings.ca.gov.
Top Jamb Mount
Left Hand Door - LH
Right Hand Reverse - RHR
Regular Arm/
Top Jamb Shoe
Connecting Rod
Forearm Tube
Forearm
Screw
1-6 = 1601SS
3 = 1603BCSS
4 = 1604BCSS
1601SS
Parallel Arm
Right Hand Door - RH
Left Hand Reverse - LHR
Optional Components
1618AS Parallel
Arm Bracket
(Used with
Parallel Arm
Installation Only)
Tools Needed
Left Hand Door - LH
Right Hand Reverse - RHR
