1.4 Specifications

Product Model
Voltage
Overall Rated Power
Processing Area
Max. Marking Speed
Marking Accuracy
Marking Depth
Focal Length
Field Lens
Aperture
Beam Combiner Lens Size
Applicable Rotary Axis Type
Model
Type
Rated Power
Adjustable Power Range 0~100%
Expected Service Life
Laser
Wavelength
Modulation Frequency
Pulse Width
Class
Operating Temperature
Range
Required Operating Software
Laser Safety Goggles Protection Level OD 6+
Applicable EZCad
Computer
Lightburn (not Included) Windows 7/8/10/11, MacOS
System
Applicable Image Formats
Dimensions
Net Weight
LYF-20MP
AC 110–120V , 60 Hz
600W
9.8×13.4 in.
250×340 mm
393.7 ips
10000 mm/s
0.01 mm
0.01 in.
0.3 mm
254 mm
175×175 mm
ø
20×2 mm
D50/D60
(Need to replace field lens with focal length below 150mm)
YDFLP-E2-20-M7-S-R YDFLP-E2-30-M7-S-R YDFLP-E2-60-M7-M-R
Fiber MOPA
20W
100,000 hr.
1064 nm
1–4000 kHz
2–500 ns
4
32–104°F
0–40°C
EZCad
Windows 7/8/10/11
BMP, GIF, JPG, JPEG, DXF, DST, Al, etc.
15.7×13.4×21.3 in.
40×34×54 cm
39.7 lb.
18 kg
3
LYF-30MP
AC 110–120V, 60 Hz
600W
11.8×13.4 in.
300×340 mm
393.7 ips
10000 mm/s
0.01 mm
0.02 in.
0.5 mm
254 mm
175×175 mm
ø
20×2 mm
Fiber MOPA
30W
0~100%
100,000 hr.
1064 nm
1–4000 kHz
2–500 ns
4
32–104°F
0–40°C
EZCad
OD 6+
15.7×13.4×21.3 in.
40×34×54 cm
39.7 lb.
18 kg
LYF-60MP
AC 110–120V, 60 Hz
600W
11.8×13.4 in.
300×340 mm
393.7 ips
10000 mm/s
0.01 mm
0.04 in.
1 mm
254 mm
175×175 mm
ø
20×2 mm
Fiber MOPA
60W
0~100%
100,000 hr.
1064 nm
1–4000 kHz
2–500 ns
4
32–104°F
0–40°C
EZCad
OD 6+
15.7×13.4×21.3 in.
40×34×54 cm
39.7 lb.
18 kg
