P900610-00
P/N 900610-00 Rev. N/C 10/2015
Parts included with this kit:
PART NO.
DESCRIPTION
126467-01
Blower Assembly L.
126467-02
Blower Assembly R.
126468-01
Speed Control Assembly
900610-00
Instruction Sheet
126972-01
Wiring Diagram
f i r e - p a r t s . c o m
WARNING: ELECTRICAL GROUNDING INSTRUCTIONS This appliance is equipped with a three-prong
(grounding) plug for your protection against shock hazard and should be plugged directly into a properly
grounded three-prong receptacle.
(Check your appliance owner's manual for specific applications and
additional instructions.)
IMPORTANT: Read entire instruction sheet before installing blower kit.
This blower kit is approved for use with models listed above. Do not
use blower kit in any other fireplace models.
If any of these parts are missing or damaged, contact dealer where
you purchased this kit. If they cannot supply original replacement
parts, either contact your nearest Parts Central or contact IHP at
IHP.US.com for information.
Note: This installation requires the gas supply line to be discon-
nected before removing log assembly. Call a qualified service
person to disconnect gas supply from fireplace.
WARNING: Turn off, unplug, and let fireplace cool
before installing blower kit. Only a qualified service
person should service and repair fireplace.
INSTALLATION INSTRUCTIONS
MODEL LPDBK2 (F2661)
LOW PROFILE DUAL BLOWER
ACCESSORY KIT
For use with:
Astria
DEVONSHIRE Series Direct Vent Fireplace
SENTINEL Series Direct Vent Fireplace
QTY.
1
Superior
1
1
DRT4036TEN/TEP and DRT4042TEN/TEP
1
Series Direct Vent Fireplace
1
For more information, visit IHP.US.com
The blower kit utilizes two rotary squirrel cage type blower with vari-
able speed control.
Note: This blower kit is approved for use with models listed on this
page. Do not use blower kit in any other fireplace models.
Models:
®
Models:
®
NOTICE: Log set/burner and hearth refractories, must be
removed before installing blower kit. Refer to owner's
manual for specific applications and additional instruc-
tions.
WARNING: A qualified service person must con-
nect and disconnect fireplace with gas supply. Follow
all local codes.
WARNING: If there is a duplex electrical outlet
installed in the right or left side of the bottom of
the fireplace base area, be sure that the electrical
power to the outlet is turned off before proceeding
with blower installation. Failure to do this may result
in serious injury.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for IHP LPDBK2
Summary of Contents for IHP LPDBK2
- Page 1 WARNING: A qualified service person must con- you purchased this kit. If they cannot supply original replacement nect and disconnect fireplace with gas supply. Follow parts, either contact your nearest Parts Central or contact IHP at all local codes. IHP.US.com for information.
- Page 2 WARNING: Reinstall any barrier removed before Refractory Right Bottom operating the fireplace. The barrier is designed to Refractory reduce the risk of burns from hot glass. Do not operate the fireplace without the barrier installed. Figure 3a - Removing Hearth Refractories IHP.US.com 900610-00N/C...
- Page 3 Note: The LPDBK2 blower kit is for application into direct-vent models listed on the front page only and is already factory pre-wired. When installing the LPDBK2 blower kit you must first check that all f i r e - p a r t s . c o m wiring connections are secure from the speed control to the blower.
- Page 4 Normally, all parts should be ordered through your IHP distributor 6. Peel off the backing paper and stick the supplied wiring diagram or dealer. Parts will be shipped at prevailing prices at time of order.
