- Page 1 SDS2000X Series Super Phosphor Oscilloscope Quick Start...
-
Page 2: Copyright Information
SIGLENT products are protected by patent law in and outside of P.R.C. SIGLENT reserves the right to modify or change parts of or all the specifications or pricing policies at company’s sole decision. Information in this publication replaces all previously corresponding material. -
Page 3: General Safety Summary
General Safety Summary Use Proper Overvoltage Protection Carefully read the following safety precautions to avoid any personal injury or damage to the instrument and any products connected to it. To avoid Make sure that no overvoltage (such as that caused by a thunderstorm) can potential hazards, please use the instrument as specified. - Page 4 Safety Terms and Symbols General Care and Cleaning Terms on the product. These terms may appear on the product: Care Indicates direct injuries or hazards that may happen. Do not store or leave the instrument in direct sunshine for long periods of DANGER time.
-
Page 5: Table Of Contents
Contents ............Copyright Information ............General Safety Summary ..............Quick start ............... The Front Panel ..............The Rear Panel ............Front Panel Overview ..............User Interface ............Using Security Lock ..............Troubleshooting ..............Contact us 1- SDS2000X Series Digital Oscilloscope... -
Page 6: Quick Start
The consigner or carrier will be responsible for damages to the instrument resulting from shipment. SIGLENT would not provide free maintenance or replacement if the instrument has been damaged in shipment. 2. Inspect the instrument... - Page 7 Power Socket If at any time the fuse requires replacement, please replace only with a fuse of the same rating as the original. If there are questions, please contact Siglent directly. 3- SDS2000X Series Digital Oscilloscope...
- Page 8 Connect the Probe SIGLENT provides passive probes for the SDS2000X series oscilloscope. Please refer to corresponding Probe User Manual for detailed technical information. 1. Connect the BNC terminal of the probe to one of the channel BNC connectors on the front panel.
- Page 9 Quick start Probe Compensation All oscilloscope probes should be properly compensated before their first use with the oscilloscope. Non-compensated or inadequate compensated probe may cause inaccurate measurement. The following steps illustrate the proper probe compensation procedure. 1. Perform step 1, 2 , 3 and 4 of “Functional Inspection”. 2.
-
Page 10: The Front Panel
The Front Panel 1.Horizontal Control 7.Trigger Control 13.Function Menus 18.USB Host 2.Auto Setup 8.Decode Control 14.WaveGen Control 19.Digital Inputs 3.Run/Stop 9.Digital Channel Control 15.Channel Vertical Control 20.Analog Inputs 4.Default 10.Math 16.WaveGen Output 21.Print 5.Clear Sweeps 11.Reference 17.Probe Compensation/ 22.Function Menu Softkeys 6.Universal Knob 12.Math/Ref Vertical Control Ground Terminal... -
Page 11: The Rear Panel
The Rear Panel 1. Handle Pull up the handle vertically for easy carrying; press it down if you do not need the handle. 2. LAN Interface The instrument can be connected to a user-network via this interface to perform remote control. 3. -
Page 12: Front Panel Overview
Front Panel Overview Horizontal Control Trigger Control Quickly enter into the horizontal Roll mode. Press the button to open trigger menu. This oscilloscope provides various trigger types: Edge, Slope, Pulse, Video, Window, Interval, Drop The timebase range is from 50 ms/div to 50 s/div. Out, Runt, Pattern and Serial Bus (I2C/SPI/UART/RS232/CAN/LIN). - Page 13 Interval Trigger Runt Trigger Runt trigger conditions can include positive and negative runts. This mode is The oscilloscope is triggered when the input signal passes through the set used to trigger the oscilloscope when pulses pass through one trigger level but trigger level on its rising edge (or falling edge) and then the trigger level again fail to pass through the other level as shown in the figure below.
- Page 14 Pattern Trigger I2C Trigger After setting the Serial 1 or Serial 2 trigger to I2C in the Trigger menu, use Identifies a trigger condition by looking for a specified pattern. This pattern the universal knob to set the trigger to a start or stop condition, restart, is a logical combination (AND/OR/NAND/NOR) of the two channels.
- Page 15 SPI Trigger After setting the serial trigger to SPI type in trigger menu, you can select to trigger on MISO data or MOSI data. The data length are variable to set from 4 to 96. UART/RS232 Trigger After setting the serial trigger to UART/RS232 type in trigger menu, you can select to trigger on start, stop, checksum error or data. The data width are variable to set from 5 to 8bits.
- Page 16 Vertical Control Vertical Scale: Sets the vertical scale of current waveform. Turn clockwise to decrease the scale value and while turn counterclockwise to increase it. During the modification, the ‘amplitude’ of the waveform will enlarge or reduce and the scale message at the right side of the screen will also change.
- Page 17 Decoding of I2C signal with a 7 bit address is shown in the following photo. Press the button to open the digital channel function menu (Optional function). The SDS2000X support 16 digital channels. Press the button to open the Math operation menu in order to select functions including add, subtract, multiply, divide, FFT, integral, differential, and square root.
- Page 18 Run Control Press the button to enable the waveform auto setup function. The oscilloscope will automatically adjust the horizontal time base, vertical scale and trigger mode according to the input signal to provide a triggered stable display. Press the button to set the state of the instrument to “RUN” or “STOP”. In the “RUN” state, the button glows yellow; In “STOP” state, the button glows red.
- Page 19 Universal Knob Function Menus Adjust Waveform Intensity/Grid Brightness/Transparency In non-menu-operation mode, (menu is hidden), turn this knob to adjust Press the button to open the cursor function. It provides manual and waveform intensity (0% ~ 100%). Turn clockwise to increase the brightness tracking cursor modes.
- Page 20 Square, Ramp, Pulse, DC, Noise, Cardiac, Gaus Pulse, ExpRise, ExpFall and Arb are supported. The max output frequency is 25MHz (Sine Wave). In addition, the user can download and output four waveforms using Siglent’s EasyWave software. SDS2000X Series Digital Oscilloscope -16...
-
Page 21: User Interface
User Interface 1. Product Logo SIGLENT is the registered trademark of our company. 2. Channel Label/Waveform Different channels are marked by different colors and the color of the waveform matches with the color of the channel. 3. Working state Available states include Arm, Ready, Trig’d, Stop, Auto. - Page 22 6. Trigger position Displays the trigger position of the waveform on the screen. 7. Frequency Counter Displays the frequency of current waveform as trigger source. 8. Sample Rate/Memory Depth Displays the current sample rate and memory depth of the oscilloscope. Use the Horizontal scale knob to modify the parameters. 9.
-
Page 23: Using Security Lock
Using Security Lock Provisions for a Kensington-style lock are provided on the rear panel of the SDS2000X (Lock is not included). To use, align the lock with the lock hole and insert, turn the key clockwise to lock the instrument and then remove the key from the lock. Security lock hole 19- SDS2000X Series Digital Oscilloscope... -
Page 24: Troubleshooting
Siglent. (4) Restart the instrument after completing the steps listed above. (5) If these steps do not solve the problem, please contact Siglent. 2. After the signal is sampled, there is no corresponding waveform displaying: (1) Check to make certain the probe is correctly connected to the signal connecting cord. - Page 25 (3) Make sure the USB disk being used is of flash type, the instrument does not support USB of hard disk type. (4) Make sure the system format of used USB disk is FAT32. (5) Restart the instrument and then insert the USB to verify operation. (6) If a problem persists, please contact Siglent. 21- SDS2000X Series Digital Oscilloscope...
-
Page 26: Contact Us
Contact us SIGLENT TECHNOLOGIES CO., LTD. Address: Blog No.4 & No.5, Antongda Industrial Zone, 3rd Liuxian Road, Bao'an District, Shenzhen, 518101, China. Tel:+86-755-36615186 E-mail:sales@siglent.com Http://www.siglent.com SDS2000X Series Digital Oscilloscope -22... - Page 27 www.siglent.com...
