Summary of Contents for Field Tuff FTF-60SCC3PT
- Page 1 3PT Cargo Car rier OWNER’S MANUAL WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Model # FTF-60SCC3PT 07192022...
-
Page 2: Intended Use
Thank you very much for choosing this product! For future reference, please complete the owner’s record below: Model: _______________ Purchase Date: _______________ Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this product before you begin using it. This product is designed for certain applications only. -
Page 3: Work Area
WORK AREA • Keep work area clean, free of clutter and well lit. Cluttered and dark work areas can cause accidents. • Keep children and bystanders away while operating a 3PT Cargo Carrier. Distractions can cause you to lose control, so visitors should remain at a safe distance from the work area. •... - Page 4 ASSEMBLY 1. Attach Left Basket (#1) and Right Basket (#2) with each 3pcs Bolt (#17), Flat Washer (#18) and Lock Nut (#19) as Part A. 2. Attach Connecting Plate (#5) to Part A with each 8pcs Carriage Bolt (#16), Flat Washer (#18) and Lock Nut (#19) as Part B.
-
Page 5: Operation
4. Secure Part C with Threaded Pin (#10), Linch Pin (#11), Spring Washer (#14) and Nut (#15) as Part D. 5. Finally assemble Part D with Long Shaft (#8) and R-Pin (#9). OPERATION WARNING: • DO NOT ALLOW passengers riding in or on the carrier. MAINTENANCE •... -
Page 6: Diagram & Parts List
DIAGRAM & PARTS LIST Part# Description Qty. Part# Description Qty. Left Basket Linch Pin Right Basket Bolt M10*145 Supporting Bracket Bolt M10*100 Connecting Tube Spring Washer 22 Connecting Plate Nut M22 Link Bar Carriage Bolt M10*20 Bushing Bolt M10*25 Long Shaft Flat Washer 10 R-Pin Lock Nut M10...
